15.6.3 ML-Series Ethernet Card Performance Monitoring Parameters
Table 15-19
Parameter
etherStatsDropEvents
rx PktsDroppedInternal
Congestion
gfpStatsRxFrame
gfpStatsTxFrame
gfpStatsRxOctets
gfpStatsTxOctets
gfpStatsRxSBitErrors
gfpStatsRxMBitErrors
gfpStatsRxTypeInvalid
gfpStatsRxCRCErrors
gfpStatsLFDRaised
gfpStatsCSFRaised
mediaIndStatsRxFrames
Truncated
mediaIndStatsRxFramesTo
oLong
mediaIndStatsRxShortPkts

15.6.3.5 ML-Series RPR Span Window

The parameters that appear in the ML-Series RPR Span window are the mandatory attributes of the
802.17 MIB. For more information on provisioning a framing mode, refer to Cisco ONS 15454
Procedure Guide.
Table 15-20
Table 15-20
Parameter
gfpStatsRxSBitErrors
gfpStatsRxMBitErrors
Cisco ONS 15454 Reference Manual, R8.5
15-38

ML-Series POS Ports Parameters for GFP-F Mode

Meaning
Number of received frames dropped at the port level.
Number of received packets dropped due to overflow in the frame buffer.
Number of received GFP frames.
Number of transmitted GFP frames.
Number of GFP bytes received.
Number of GFP bytes transmitted.
Sum of all the single bit errors. In the GFP CORE HDR at the GFP-T
receiver, these are correctable.
Sum of all the multiple bit errors. In the GFP CORE HDR at the GFP-T
receiver, these are uncorrectable.
Number of receive packets dropped due to Client Data Frame UPI errors.
Number of packets received with a payload FCS error.
Count of core HEC CRC multiple bit errors.
Note This count is only of eHec multiple bit errors when in frame. This
can be looked at as a count of when the state machine goes out of
frame.
Number of GFP Client signal fail frames detected at the GFP-T receiver.
Number of received frames that are too long. The maximum is the
programmed maximum frame size (for VSAN support); if the maximum
frame size is set to default, then the maximum is the 2112 byte payload
plus the 36 byte header, which is a total of 2148 bytes.
Number of received frames with CRC error.s
Number of received packets that are too small.
defines the ML-Series Ethernet card RPR Span parameters.

ML-Series RPR Span Parameters for 802.17 MIB

Meaning
Sum of all the single bit errors. In the GFP CORE HDR at the GFP-T
receiver, these are correctable.
Sum of all the multiple bit errors. In the GFP CORE HDR at the
GFP-T receiver, these are uncorrectable.
