Chapter 1
Shelf and Backplane Hardware
Protection schemes and EIA types can affect slot compatibility.
Note
Table 1-32
Symbol
Color/Shape
Orange/Circle
Blue/Triangle
Purple/Square
Green/Cross
Red/P
Red/Diamond
Gold/Star
Blue/Hexagon
Table 1-33
ONS 15454 optical, electrical, and Ethernet cards.
Table 1-33
Card
DS1-14
DS1N-14
DS1/E1-56
DS3-12
DS3N-12
DS3-12E
DS3N-12E
DS3XM-6
DS3XM-12
78-18106-01
Slot and Card Symbols
Definition
Slots 1 to 6 and 12 to 17. Only install ONS 15454 cards with a circle symbol on the
faceplate.
Slots 5, 6, 12, and 13. Only install ONS 15454 cards with circle or a triangle symbol
on the faceplate.
TCC2/TCC2P slot, Slots 7 and 11. Only install ONS 15454 cards with a square
symbol on the faceplate.
Cross-connect (XCVT/XC10G) slot, Slots 8 and 10. Only install ONS 15454 cards
with a cross symbol on the faceplate.
Protection slot in 1:N protection schemes.
AIC-I slot (Slot 9). Only install ONS 15454 cards with a diamond symbol on the
faceplate.
Slots 1 to 4 and 14 to 17. Only install ONS 15454 cards with a star symbol on the
faceplate.
(Only used with the 15454-SA-HD shelf assembly) Slots 3 and 15. Only install
ONS 15454 cards with a blue hexagon symbol on the faceplate.
lists the number of ports, line rates, connector options, and connector locations for
Card Ports, Line Rates, and Connectors
Ports
Line Rate per Port
14
1.544 Mbps
14
1.544 Mbps
56
1.544 Mbps
12
44.736 Mbps
12
44.736 Mbps
12
44.736 Mbps
12
44.736 Mbps
6
44.736 Mbps
12
89.472 Mbps
1.17.1 Card Slot Requirements
Connector Types
SMB w/wire wrap
adapter, AMP Champ
connector
1
SMB w/wire wrap
adapter, AMP Champ
connector
2
SMB w/wire wrap
adapter, AMP Champ
connector
1
SMB or BNC
1
SMB or BNC
1
SMB or BNC
1
SMB or BNC
1
SMB or BNC
1
SMB or BNC
Cisco ONS 15454 Reference Manual, R8.5
Connector
Location
Backplane
—
—
Backplane
—
Backplane
—
Backplane
Backplane
1-73
