Card Installation
Use the clips on the male AMP Champ connector to secure the connection.
Step 3
The female connector has grooves on the outside edge for snapping the clips into place.
To install optical cable, you must first install optical cards.
Note
1.12 Card Installation
This section describes the how to install ONS 15454 cards. The procedure for installing ONS 15454
cards is nearly identical for each card. AIC card installation is slightly different from all other cards and
is described in its own procedure. The XC/XCVT /XC10G and TCC+ installation procedures are
virtually identical and are described in one procedure. Installation for all other cards is the same and is
covered by one procedure.
The order in which you install cards is important. The proper sequence follows:
1.
2.
3.
4.
5.
6.
Because all other cards boot from the active TCC+ card which houses the ONS 15454 software, you
Note
must install the TCC+ card before booting any other cards. See
for information about the TCC+ card and software versions.
Note
Before installing cards, verify that the power is turned on.
ONS 15454 cards have electrical plugs at the back that plug into electrical connectors on the shelf
assembly backplane. When the ejectors are fully closed, the card plugs into the assembly backplane.
Figure 1-29
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not
directly touch the backplane with your hand or any metal tool, or you could shock yourself.
Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the
Caution
wristband cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Class I (21 CFR 1040.10 and 1040.11) and Class 1M (IEC 60825-1 2001-01) laser products.
Warning
Cisco ONS 15454 Installation and Operations Guide
1-44
TCC+ cards
XC/XCVT/XC10G cards
Optical cards
Electrical cards
Ethernet cards
AIC card
shows card installation.
Chapter 1
Hardware Installation
Chapter 2, "Software Installation"
November 2001
