Chapter 13 Identifying Traffic with Access Lists
Show the original access list configuration:
hostname(config)# sh access-list test
access-list test; 13 elements
access-list test line 1 extended permit tcp host 10.1.1.6 host 10.1.1.20 eq www (hitcnt=0) 0x1d3335f6
access-list test line 2 extended permit tcp any host 10.1.1.90 eq ssh (hitcnt=0) 0x9f0b14e0
access-list test line 3 extended permit tcp any host 10.1.1.90 eq ftp (hitcnt=0) 0x7d023e5f
access-list test line 4 extended permit tcp any object-group dns-servers eq domain 0xb4b0751d
access-list test line 4 extended permit tcp any host 10.10.10.5 eq domain (hitcnt=0) 0x9664696e
access-list test line 4 extended permit tcp any host 10.10.10.6 eq domain (hitcnt=0) 0xde9a7aec
access-list test line 4 extended permit tcp any host 10.10.10.7 eq domain (hitcnt=0) 0x5847c29a
access-list test line 4 extended permit tcp any host 10.10.10.8 eq domain (hitcnt=0) 0xa4246eba
access-list test line 4 extended permit tcp any host 10.10.10.9 eq domain (hitcnt=0) 0x85fc0e4a
access-list test line 5 extended permit udp any any eq domain (hitcnt=0) 0xbaf2384c
access-list test line 6 extended permit tcp 10.1.1.0 255.255.255.0 any (hitcnt=0) 0xd07a176b
access-list test line 7 extended permit icmp any any (hitcnt=0) 0xb422e9c2
access-list test line 8 extended permit udp any any neq domain (hitcnt=0) 0x8e2ee97e
access-list test line 9 extended permit tcp any host 10.10.10.5 (hitcnt=0) 0xaa819def
Enable access list group optimization:
hostname(config)# access-list optimization enable
ACL group optimization is enabled
hostname(config)#
Access Lists Optimization Complete
Access Rules Download Complete: Memory Utilization: < 1%
When optimization is enabled, rules are optimized and downloaded in the NPs. The original
Note
non-optimized rules become inactive. Any addition/deletion of any rule must take place on the original
non-optimized access lists. Whenever a new rule is added/deleted, the optimization process is repeated
and the message "Access Lists Optimization Complete" defines the end of the optimization process.
During that processing time, some of the access lists information may not be accurate until the
optimization process is complete.
Show the non-optimized (original) access list again:
hostname(config)# show access-list test
access-list test; 13 elements
access-list test line 1 extended permit tcp host 10.1.1.6 host 10.1.1.20 eq www (hitcnt=*) 0x1d3335f6
access-list test line 2 extended permit tcp any host 10.1.1.90 eq ssh (hitcnt=*) 0x9f0b14e0
access-list test line 3 extended permit tcp any host 10.1.1.90 eq ftp (hitcnt=*) 0x7d023e5f
access-list test line 4 extended permit tcp any object-group dns-servers eq domain 0xb4b0751d
access-list test line 4 extended permit tcp any host 10.10.10.5 eq domain (hitcnt=*) 0x9664696e
access-list test line 4 extended permit tcp any host 10.10.10.6 eq domain (hitcnt=*) 0xde9a7aec
access-list test line 4 extended permit tcp any host 10.10.10.7 eq domain (hitcnt=*) 0x5847c29a
access-list test line 4 extended permit tcp any host 10.10.10.8 eq domain (hitcnt=*) 0xa4246eba
access-list test line 4 extended permit tcp any host 10.10.10.9 eq domain (hitcnt=*) 0x85fc0e4a
access-list test line 5 extended permit udp any any eq domain (hitcnt=*) 0xbaf2384c
access-list test line 6 extended permit tcp 10.1.1.0 255.255.255.0 any (hitcnt=0) 0xd07a176b
access-list test line 7 extended permit icmp any any (hitcnt=0) 0xb422e9c2
access-list test line 8 extended permit udp any any neq domain (hitcnt=*) 0x8e2ee97e
access-list test line 9 extended permit tcp any host 10.10.10.5 (hitcnt=0) 0xaa819def
Some hit count values are represented with an asterisk '*'. An asterisk means that the rule has been
Note
merged with other rules and thus the hit count cannot be accurate. Hit counts for optimized rules
represent the cumulative value of all of the hit counts of the merged or removed rules. There is no way
to determine the hit count for every merged or removed rule.
Show the optimized access list:
hostname(config)# show access-list test optimization
access-list test;
13 elements before optimization
7 elements after optimization
Reduction rate = 46%
