2. Unpacking and Installation

2.1 Before Starting the Work

Be sure to observe the following when installing the machine:
1. If the machine is moved from a cold to warm place for installation, con-
2. If flights of stairs are used to move the machine into or out of the site of
3. Shift up the two adjusters found on the machine's bottom (front) to
4. Be sure to work in a group of three or more when installing the ma-
COPYRIGHT © 2001 CANON INC.
densation can occur in its pickup/feed assembly. Leave the machine
alone without unpacking for an hour or more before starting the work.
(The term condensation refers to the formation of droplets of water on a
metal surface caused by rapidly cooling moisture in the air.)
installation, be sure to observe the following:
2.1 Take out the ADF assembly, fixing/feeding assembly, and duplexing
unit, and move them separately from the body.
2.2 When lifting the machine, do not use its four grips (left, right); in-
stead, hold it by its four bottom corners.
2.3 The machine weighs 210 kg. Be sure to work in a group of four.
make sure that they are released. The adjusters can slip off while the
machine is being moved. Be sure to pay attention not to lose them.
chine. When removing the pad and bottom plate, arrange one person at
the rear and one person at the front to hold the grips while one person
engages in removal.
