4. Using the Machine

4.1 Turning On the Power Switches
The machine possesses two switches: main power switch and control panel power switch.
Normally, it is supplied with power when the main power switch is turned on (i.e., other
than in energy saver mode, low power mode, or sleep mode).
Counter
Check
Display Contrast
[1] Control panel power switch
[2] Main power lamp
COPYRIGHT © 2001 CANON INC.
[1] [2]
Energy Save
ON/OFF
Reset
1 2 3
Stop
Guide Start
4 5 6
Additional Function
7 8 9
Clear
0 C
ID
Processing
Power
Error
/Data
[3] Main power switch
F01-401-01 Arrangement of Switches
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 1 GENERAL DESCRIPTION
[3]
1-19 S
