2. Image Formation

2.1 Outline
The machine uses an indirect electrophotographic method to form images, and is con-
structed as follows:
Scanning lamp
Pre-exposure LED
Fixing assembly
Cleaning assembly
COPYRIGHT © 2001 CANON INC.
Primary charging assembly
Separation
claw
Separation
charging assembly
F01-201-01 Construction of the Machine
2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 1 GENERAL DESCRIPTION
Copyboard glass
Pre-transfer
charging assembly
Transfer assembly
Pickup (deck/cassette)
Potential sensor
Dust-collecting roller
Pickup
(manual feed tray)
1-7 P
