9.6.10 Removing the Reversal Sensor 1
1) Slide the duplex unit out of the ma-
chine.
2) Remove the two mounting screws [1],
and detach the sensor together with its
base [2].
3) Disconnect the connector [3], and de-
tach the sensor [4].
9.6.11 Removing the Reversal Sensor 2
1) Slide the duplex unit out of the ma-
chine.
2) Remove the two mounting screws [1],
and detach the sensor together with its
base [2].
COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 5 PICK UP/FEEDING SYSTEM
[1]
F05-906-17
[3]
F05-906-18
[1]
F05-906-19
[2] [1]
[4]
[2] [1]
5-75 P
