5. Drum Cleaner Unit

5.1 Outline

The following component parts are associated with the drum cleaner unit:
COPYRIGHT © 2001 CANON INC.
Auxiliary roller
Waste toner
feedscrew
F04-501-01
2000 2000 2000 2000
CANON iR5000i/iR6000i REV.0 JUNE 2001
CHAPTER 4 IMAGE FORMATION SYSTEM
Pre-exposure lamp (LED)
Cleaning blade
Separation claw
Magnet roller
4-43 P
