CHAPTER 7 EXTERNALS AND CONTROLS

5.3.4 Removing the Control Panel Family PCB

1) Remove the control panel.
2) Remove the shielding plate.
3) Remove the mounting screw, and detach
[1] [1]
the control panel family PCB [4].
F07-503-08
7-21 P
