Chapter 9. Communication
Register Register
(in Hex) (in Dec.)
2418 9240
241A 9242
241C 9244
241E 9246
2420 9248
2422 9250
2424 9252
2426 9254
2500 2500 9472
2502 9474
2504 9476
2506 9478
2508 9480
250A 9482
250C 9484
250E 9486
2510 9488
2540 2540 9536
2542 9538
2544 9540
2546 9542
2548 9544
254A 9546
2580 2580 9600
2582 9602
2584 9604
2586 9606
2600 2600 9728
2602 9730
2604 9732
2606 9734
2640 2640 9792
2642 9794
2644 9796
2646 9798
2648 9800
264A 9802
264C 9804
146
Table 17: Modbus Register Map (cont.)
Access Description
Level
User Ch1 Fluid Static Density
User Ch1 Fluid Reference Density
User Fluid Temperature
User Ch1 XDR space
User Ch1 Calibration Factor
User Ch1 Kinematic Viscosity
User Ch1 XDR Temperature
User eCh1 Goycol
User Ch1 Pipe Material
User Ch1 Lining Material
User Ch1 XDR Type
User Ch1 XDR frequency
User Ch1 XDR wedge type
User Ch1 Fluid Type
User Ch1 Lining existence
User Ch1 Traverse number
User Ch1 Couplant type
User Ch1 Enable Reynolds Correction
User Ch1 Enable Active MultiK
User Ch1 MultiK Type
User Ch1 MultiK Pairs
User eCh1 Density
User eCh1 DensityPairs
User Ch1 Peak%
User Ch1 Min Peak%
User Ch1 Max Peak%
User Ch1 Enable Tracking Windows
RO Ch1 Velocity
RO Ch1 Volumetric
RO Ch1 Standard Volumetric
RO Ch1 Mass Flow
RO Ch1 Batch fwd totals
RO Ch1 Batch rev totals
RO Ch1 Batch net totals
RO Ch1 Batch totals time
RO Ch1 inventory fwd totals
RO Ch1 inventory rev totals
RO Ch1 inventory net totals
RO/
RW
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
®
