Page 1 Vertex M Continuous Gas Monitor Technical Handbook • Table of Contents • Troubleshooting • Optional Relay Specifications • Introduction • Installation Drawings • Network Interface and Options • Installation • Specifications • 4-20mA Analog Output Option • Startup • Detectable Gases •...
Page 2 Vertex M 24-Point Continuous Monitor Vertex M Continuous Monitor Symbols Symbol Description Power on Power off Potential damage to the device or other property, maintenance N OT I C E procedures, and “refer to manual” instructions. CAUTION Lifting instructions, low clearances, slipping/tripping hazards, minor corrosive dangers.
Page 3: Emc Considerations
Vertex M 24-Point Continuous Monitor EMC Considerations Cabling Your Honeywell Analytics monitor has been designed At a very minimum, all cables should include a braided to comply with applicable Electromagnetic Compatibility shield. Ideal results have been obtained with twisted (EMC) standards at the time of manufacture. The design pair cabling which has a foil shield surrounding each includes filtering, shielding and bypassing techniques.
Page 4: Table Of Contents
EMC Considerations ............i Introduction ..............2-2 Cabling ................ii Surveying the Installation Site ........2-2 Connectors ..............ii Placement of the Vertex M System ......2-2 Exposure to Dust and Humidity .......2-2 Introduction ........... 1-1 Sample Transport Time ..........2-2 System Overview ............1-2 Instrument Dimensions ..........2-2...
Page 5 Vertex M 24-Point Continuous Monitor Configuration Utility ............3-6 Run Time Options ..........4-26 Define Gas Location ..........3-17 Flow Calibration ............4-32 Configure Analyzers and Points ......3-19 Maintenance ............4-40 Set Analyzer Window ..........3-20 Diagnostics ............4-41 Configure Point ............3-21 Service ..............4-44 Define and Assign Relays ........3-28 Security Access .............4-47...
Page 6 Ethernet/CIP (P/N1295-0519) ......... F-20 Pyrolyzers ............... D-2 Configuring the IP Address ........F-21 All Analyzers ............D-2 Vertex M Remote Display Setup ......F-21 Power Distribution Module ........D-2 Checking Remote Session Count ......F-21 Components .............. D-2 Determining the IP Address ........F-22 All Analyzers ............
Page 7 Create HMI account .......... F-22 Starting the Niagara Remote Display ....F-22 Full Desktop Station Setup ........F-25 Add Honeywell software to Desktop ....F-25 Create a “Honeywell Analytics” account .... F-25 Create Group “VertexDCOMUsers” ....F-25 Disable Windows Firewall ........F-27 Configure DCOM ..........
Page 8: Introduction
Vertex M 24-Point Continuous Monitor 1 Introduction Vertex M Technical Handbook...
Page 9: System Overview
Honeywell Analytics Inc. • Storing the alarm information in a database 405 Barclay Boulevard The Vertex M System provides fast response to a wide Lincolnshire, IL 60069 USA www.honeywellanalytics.com range of gases. Each location may be up to 400 ft (122 m) from the Vertex M System.
Page 10: Vertex M Front
Vertex M 24-Point Continuous Monitor 1.2.1 Vertex M Front Sample Tubing, Exhaust and Wiring Ports Relay PLC (behind monitor) Relay Options Network Interface Options Touch Screen System Controls Universal Chemcassette ® Analyzer Pyrolyzer Analyzer Analyzer Front Analyzer Side Panel Section 1 - Introduction...
Page 11: Vertex M Back
Vertex M 24-Point Continuous Monitor 1.2.2 Vertex M Back Back of Pyrolyzing Chemcassette Analyzer Data Acquisition Computer (rear) 4-20mA Option PLC Pyrolyzer step-up/Isolation transformer Section 1 - Introduction...
Page 12: Sample Tubing, Exhaust And Wiring Ports
Vertex M 24-Point Continuous Monitor 1.2.3 Sample Tubing, Exhaust and Wiring Ports AC Input 0.75 in pipe thread System Exhaust 0.5 in (12.7mm) tubing Analyzer 3 Sample Ports Alarm Wiring Conduit Plate Analyzer 2 Sample Ports 2 in (50.8mm) Analyzer 1 Sample Ports...
Page 13: Analyzer Side Panel
Vertex M 24-Point Continuous Monitor 1.2.4 Analyzer Side Panel Exterior View Slide Latch Access Screws Internal View Analyzer CPU ChemCam Option Sample Pressure Transducers Sample Flow Transducers Sensor Interface PCB Proportional Valve Filters Section 1 - Introduction...
Page 14: Analyzer Front
Vertex M 24-Point Continuous Monitor 1.2.5 Analyzer Front 1.2.6 System Controls Rack Power Switch and Circuit Breaker Power Distribution Module 24VDC Power Supplies Analyzer DC and Pyrolyzer AC Analyzer Status LED Power Switches with Indicators Pyrolyzer Analyzer Data Acquisition Computer (DAq)
Page 15: Data Acquisition Computer (Rear)
Vertex M 24-Point Continuous Monitor 1.2.7 Data Acquisition Computer (rear) USB (3) USB Host Device Power Internal Ethernet Touchscreen Serial Com2 video External Ethernet (not used) Mouse Speakers (not used) Keyboard Microphone Serial interface (not used) USB, USB (Com8) for touchscreen...
Page 16: Back Of Chemcassette Module
Vertex M 24-Point Continuous Monitor 1.2.8 Back of Chemcassette Module ® ChemCam USB Connection (Optional) Analyzer Communications (Ethernet) Analyzer 24V Power Supply Multi-Function Connector Circular Tubing Harness Cable Carrier Note: Connection secured by slide latch. Push up to open. Push down to close.
Page 17: Main Plc
Vertex M 24-Point Continuous Monitor 1.2.9 Main PLC PLC Processor DH485/RS232 Module Interface Module Expansion slot for optional Communications Interface Advanced Interface DH485 Link Optional Relay Converter Coupler Modules PLC Power Supply Section 1 - Introduction 1-10...
Page 18: 4-20Ma Analog Output Option Plc
Vertex M 24-Point Continuous Monitor 1.2.10 4-20mA Analog Output Option PLC Power Supply 4-20mA Output Modules (6X) Section 1 - Introduction 1-11...
Page 19: Menu Map
Vertex M 24-Point Continuous Monitor 1.3 Menu Map Main Screen System Point Detail Display Area Display Area Project Review Menu Buttons Functions Functions Log In Event History Security Configuration Run Time and Log Out Service Diagnostics Maintenance Utility Options Access...
Page 20: Analyzer Modules
24-Point Continuous Monitor 1.4 Analyzer Modules 1.5 Sampling System The Vertex M System is populated with one or more Each Analyzer module is a monitoring center for types of analyzer modules. Each system may contain sampling lines from sample locations. As they apply to Chemcassette modules or Pyrolyzer modules.
Page 21: Chemcassette ® Detection System
Chemcassette tape. ® contained, microprocessor controlled analyzer that occupies one slot in a Vertex M. Sample lines and the vacuum source are connected to the Chemcassette ® via a single 10-tube connector. The system powers up in the same state as when powered down.
Page 22: Chemcassette ® Tapes
Vertex M 24-Point Continuous Monitor 1.6.3 Chemcassette Tapes ® Chemcassette tapes are tagged with a radio frequency ® identification (RFID) tag to automatically identify the following: • Serial number • Gas family/ tape type • Revision level • Expiration date of the tape •...
Page 23: Pyrolyzer Module Detection System
50 feet. the NF concentration. The pumps are located in the bottom of the Vertex M The Vertex M pyrolyzer module detects NF only and System cabinet inside a sound-deadening enclosure cannot be bypassed to detect mineral acids.
Page 24: Control System
1.10.1 Data Acquisition Computer The data acquisition computer (DAq) is the central processor for the Vertex M System. It configures the analyzers, stores data and provides a network interface for data transfer to other computers. System display and operator control is through an LCD touchscreen w/ on-screen keyboard or included external keyboard.
Page 25 Vertex M 24-Point Continuous Monitor Section 1 - Introduction 1-18...
Page 26: Installation
Vertex M 24-Point Continuous Monitor 2 Installation Vertex M Technical Handbook...
Page 27: Introduction
Vertex M 24-Point Continuous Monitor 2.1 Introduction You can place the Vertex M System up to 400 ft. (122 m) from sample locations. The installation and initial start-up procedure for the Vertex M System consists of seven steps, described 2.2.2 Exposure to Dust and Humidity...
Page 28: Sample Line Particulate Filter Use
® Water condensation in the sample lines could cause Install sample lines from each location to the top of the false alarms. Vertex M System. This procedure involves: Note: • 2.4.1 Sample Line Installation Requirements Variables such as airflow, the molecular weight and temperature of the sample gas, and the physical •...
Page 29: Sample Line Connections
Pump Exhaust Line for connection.) This section describes exhaust connections and Note: installation. The Vertex M System is equipped with a vacuum pump that is located in the bottom of the Vertex Always perform a leak check after installing sample lines. See Section 3.8 Leak Checking Sample Lines...
Page 30: Exhaust Line Installation Requirements
2.6 Electrical Power x 1/2 in. (13 mm) O.D. Teflon tubing. Insert the tubing The Vertex M System requires a connection to a into the exhaust port on the top of the unit to the depth source of electrical power. An easily accessible service of 0.9 in.
Page 31: Connecting Ac Power
The Vertex M System requires a dedicated AC circuit rated at either 110 or 230 volts, 50/60 Hz, 15 Amp single Analyzer / Pyrolyzer phase.
Page 32: Printer
2.7.2 External Network Connection The on-screen keyboard operates similar to a standard keyboard except when using modifier keys (CTRL, ALT, The Vertex M System can be connected to an external or SHIFT). Ethernet network at the port shown. To use modifier keys: 1.
Page 33: Network Computer Security
24-Point Continuous Monitor 2.7.3 Network Computer Security 2.8.1 Relay Contacts The Vertex M relies on the HMI system of accounts The Vertex M System has form-A, single-pole, single- and passwords to prevent unauthorized tampering throw relays that activate external alarm devices.
Page 34: Wiring Guidelines
• Do not switch DC current with the relay 1998-0219 Detector Testing Protocols contact unless you are using counter electromotive force (CEMF) protection such as a suppression diode. • Do not use the Vertex M System power supply for external alarm power. Section 2 - Installation...
Page 35 Vertex M 24-Point Continuous Monitor Section 2 - Installation 2-10...
Page 36: Startup
Vertex M 24-Point Continuous Monitor 3 Startup Vertex M Technical Handbook...
Page 37: Initial Startup
• AC power connection 3.1.1 Initial Startup • Relay wiring Use this section to turn on your Vertex M System and to Section 2 Installation for connection details. configure the analyzer modules for specific gas locations. 3.4 Power Up There are six parts to this startup procedure: Use the rack power switch behind the front door to •...
Page 38 Vertex M 24-Point Continuous Monitor time in millesconds Mon State Alarm State Fault State none black green maintenance amber black idle instrument amber black black black none green black pyrolyzer m or i green black amber warmup green black none...
Page 39: Start Program
Vertex M program. After the two-to-three minute startup sequence, the Vertex M main screen opens. Note: Any time the Vertex M System is powered up, loss of communications may cause maintenance faults. Section 4.5.4 Event List for instructions to clear faults.
Page 40 Vertex M 24-Point Continuous Monitor Figure 3-1. Vertex M Main Screen Section 3 - Startup...
Page 41: Configuration Utility
24-Point Continuous Monitor 3.6 Configuration Utility Before the Vertex M System can begin monitoring, you must create a configuration profile. The configuration profile stores all of the monitor settings in a single file on the hard drive. Configuration profiles include system level information, point settings and analyzer information.
Page 42 24-Point Continuous Monitor Information and Options Define and Assign PLCs A display of key parameters about Associate relays with software alarms and faults. the Vertex M system. See Summary Information A tabular listing of the configuration profile Options Select a tab to enter information and set parameters common to all points and modules.
Page 43 PLCs. If the Vertex M System is in a monitoring state, the program will open a dialog box to verify that it is okay to take the Vertex M System File Save/Save As... out of monitor during the profile installation.
Page 44 Inverted Gas Alarm Relays Vertex M alarm relays, by default, are normally open (de-energized) when no alarm condition exists. If this option is checked, the alarm relays will be normally closed (energized) when there is no alarm.
Page 45 Disabled Alarm Action - Gas Relays Disabled or Full (No Gas Events) This setting effects the operation when alarms are disabled using the Runtime Options screen. If “Full” is selected, Vertex M will not generate an alarm event for the affected point(s) and none of the associated actions such as relay actuation will occur.
Page 46 Vertex M 24-Point Continuous Monitor Internal Filter Life (in Days) Set the number of days the filters will last before they need to be replaced. When the target is reached, this setting will trigger a maintenance fault to replace filter.
Page 47 The system calculates and displays the TWA after each 8-hour TWA cycle. The default setting is 04:00 indicating that the Vertex M will run three successive TWA periods from 04:00 to 11:59, 12:00 to 19:59, 20:00 to 03:59. Remember, the Vertex M System uses a 24-hour clock.
Page 48 Note: Setting the Vertex M System to continuously log concentration data on a 3-analyzer system requires approximate- ly 15 megabytes of disk storage per day at the fastest logging rate of once every 5 seconds. Purge data often to avoid filling available disk space.
Page 49 Retention periods are selected as either days or weeks. Valid entries for the period are positive numbers from 1-99. Vertex M will not recalculate the values when the unit is changed. For example, if the purge period is 14 days and you change “days” to “weeks”, Vertex M will set the period to 14 weeks. Vertex M performs the record purge as the data acquisition computer clock passes midnight.
Page 50 Vertex M 24-Point Continuous Monitor 20 mA PLC Installed Leave this box UN-checked regardless of whether a 4-20mA PLC is installed. Appendix G for Analog Output option configuration. Fieldbus Fieldbus Parameters Use this setting to select the These settings allow the user to change PLC network interface that is installed.
Page 51 32 characters. Use mg/m3 units Select to display concentrations in milligrams per cubic meter. If this option is not selected, Vertex M displays concentrations in parts-per-million (ppm) or parts-per-billion (ppb). User File Rev Allows the user to assign a revision number to a configuration profile.
Page 52: Define Gas Location
Clears every entry in the list. Creates a new entry in the gas location list using the entered short and long names. Short names Enter up to 12 characters. Vertex M Long names displays the short name where space Enter up to 35 characters.
Page 53 Vertex M 24-Point Continuous Monitor Gas Location List Select desired gas location from this list. For points with no assigned location, select (default). Points assigned to default Point Map location will automatically be given location Select point to add or remove it from the names based on the point’s position in the...
Page 54: Configure Analyzers And Points
Press “Configure Analyzer/Points” to change the right side of the Configuration window to a display representing physical layout of the Vertex M System. Each slot is represented by a two-part button. When you have configured an analyzer, the top of the button displays the type of analyzer and the gas family.
Page 55: Set Analyzer Window
ChemCam AutoPicture When either ChemCam for Level 1 or Level 2 gas is selected, a gas alarm signals the Vertex M System to store a picture of the stain the next time it advances the Chemcassette tape.
Page 56: Configure Point
Vertex M 24-Point Continuous Monitor 3.6.4 Configure Point The Configure Point window provides the following options for each point: Select the specific target gas Configure concentration logging Designate the location of the target gas Configure point-specific event help Set alarm levels...
Page 57 Appendix A Detectable Gases for a list of default alarm levels. You may enter new levels only within the range of the Vertex M detection system. Make the gas assignments before changing alarm levels. Changing the gas automatically resets alarm level settings to the factory defaults.
Page 58 Note: Setting the Vertex M System to continuously log concentration data on a 3-analyzer system requires approximate- ly 15 megabytes of disk storage per day. Purge data often to avoid filling available disk space. Section 3 - Startup...
Page 59 Vertex M 24-Point Continuous Monitor Units Selects the unit of measure to display target gas concentrations. This selection applies to this screen only and does not effect displays during normal operation or events. Unit choices are: Parts-per-million or parts-ber-billion. Appendix A Detectable Gases for definition.
Page 60 Vertex M 24-Point Continuous Monitor Perform Optional Line Integrity Test Check this box to perform a sample line integrity test. Appendix A Line Integrity Test Option. Disable Point No Monitoring Select “Disable Point” for points not needed. Associated (*.HTM) File You may link a user-generated HTML file to this point.
Page 61 Vertex M 24-Point Continuous Monitor PLC Network Generate Window Zero Use to set communication parameters for the optional PLC Network interface. Reset Faults F.8 DF1 Interface (P/N1295-0343) Window Zero Reset events F.9 Modbus Plus Interface (P/N1295-0330) are generated when un- usual optics readings occur.
Page 62 Vertex M 24-Point Continuous Monitor Virtual Reference Function Number of Time to The Virtual Reference option reduces the possibility Chemcassette Windows confirm Pulled (sec) that a non-gas event will result in a concentration or alarm. When enabled, it maintains a record of spe-...
Page 63: Define And Assign Relays
Vertex M uses a two-part display to configure relays. The Configure PLC window displays the available relay cards and contacts. In a second window, Vertex M also displays a representation of the analyzers installed in the system. Appendix A Optional Relay Specifications for a complete listing of alarm relay specifications.
Page 64: Configure Plc
Clear All PLC Relay Cards Erases the alarm and fault relay definitions Up to 4 relay cards populate the Vertex M System. The cards are numbered 3-6. Set Default Relays per Card Sets all relays to the initial default mappings Relays are located on relay cards;...
Page 65: Set Alarm Relays
Vertex M 24-Point Continuous Monitor to the PLC configuration without changing the relay Changing the number of fault relays from 14 to 12 will assignments. result in two additional (and undefined) alarm relays being available at card 3 relays 12 and 13. Existing relay definitions are not moved.
Page 66 Vertex M 24-Point Continuous Monitor Squares that represent the point or Clear all alarm points to associate with the relay definitions from relays Set type of alarm Selected relay in the relay block Section 3 - Startup 3-31...
Page 67: Set Fault Relays
• Instrument faults indicate a loss of monitoring on one or more points. • Maintenance faults indicate the Vertex M System requires attention but is continuing to monitor. Note: The number of relays used for fault indication is con- figurable.
Page 68 Vertex M 24-Point Continuous Monitor Square that represents the Clears all fault definitions analyzer or analyzers to from all relays associate with the relay Selected relay in the relay block Set type of fault Section 3 - Startup 3-33...
Page 69: Profile Management-File Menu
Copies the configuration When you make any changes to the configuration of one analyzer to any profile, Vertex M will always prompt you to save the other analyzer in the system. There are two change before closing the Configuration window.
Page 70: Verify Flow Rates And Supply Vacuum
Vertex M 24-Point Continuous Monitor 3.8 Verify Flow Rates and Supply 3.8.1 Verify Flow Rates The Authorized Service window displays the flow range Vacuum in bar graph form for each point of the selected analyzer. After you have configured all analyzers, loaded...
Page 71 Vertex M 24-Point Continuous Monitor Selection Pad Flow (cc/min) The real-time sample flow to the point. Point Vacuum (in Hg) Point Vacuum indicates the restriction from sample line length and the pressure developed by shared lines. Supply Vacuum Typical supply vacuum is 9-12 in.
Page 72 Vertex M 24-Point Continuous Monitor Target Flow A horizontal red line indicates the target flow rate required by the Vertex M System for correct analysis. The target flow rate is 180 cc/min. +/-5% (171-189 cc/min.) Flow Rate A floating white box indicates the actual flow rate.
Page 73 Vertex M 24-Point Continuous Monitor Proportional Value Range Minimum Flow A vertical green bar displays the dynamic The minimum flow possible with range over which the proportional valve the attached sample line and orifice. can adjust the flow rate. Indicated numerically by Minimum Flow and Maximum Flow.
Page 74: Leak Checking Sample Lines
7 indicates either a leak in the sample line or a faulty sample inlet connection. To troubleshoot the condition, disconnect the sample line at the inlet port at the top of the Vertex M cabinet. Securely plug the inlet port and repeat the above leak check procedure.
Page 75: Moving To A New Site
24-Point Continuous Monitor 3.11 Moving to a New Site CAUTION Before moving the Vertex M to a new site, use the following procedures to prevent loss of data or damage Leaks in the exhaust tubing connection can cause to the monitor.
Page 76: System Shutdown
24-Point Continuous Monitor System Shutdown CAUTION Failure to properly shut down the Vertex M could result in system file corruption. 1. Exit the Vertex program. Touch Project and then Stop Project. 2. In the Windows taskbar touch Start and then Shut Down.
Page 77: Operation
Vertex M 24-Point Continuous Monitor 4 Operation Vertex M Technical Handbook...
Page 78: Introduction
4.1 Introduction 4.2 Monitoring Mode Overview This chapter describes Vertex M operation including Monitor mode is the Vertex M System’s standard monitoring, system control and data viewing. operating state. Upon power up, the monitor performs initialization routines and returns to the same state as This chapter includes the following sections: when powered down.
Page 79: Main Screen
Vertex M 24-Point Continuous Monitor 4.3 Main Screen The Vertex M System opens the main screen after power up. Vertex M divides the main screen into three areas: • System display • Point detail • Function buttons Point Detail System Display...
Page 80: System Display Area
Vertex M 24-Point Continuous Monitor 4.3.1 System Display Area The System Display Area displays information about all of the points in the Vertex System. Each of the 72 blocks in the System Display Area represents one point. A group of eight blocks represents an analyzer block.
Page 81 Vertex M 24-Point Continuous Monitor Status Indicators The Vertex System displays only the short names of the location and target gases within each point block. The indicator displays brief information about analyzer During normal monitoring, the background color of each status such as faults, warnings or maintenance block is white.
Page 82 “OFF” on a white background if the pump will change to “GOOD”. is not running. Honeywell Analytics recommends that pumps be The top row indicates what is known about pump alternated periodically to insure availability according health. The indicator will display “GOOD” with a green to your facility’s schedule.
Page 83 Vertex M 24-Point Continuous Monitor Fault Indicators In addition to changing color, an event window opens indicating a new event. A yellow square inside the status bar in the analyzer block indicates an analyzer-specific fault. A yellow square inside of the point block indicates a point-specific fault.
Page 84: Point Detail Display Area
Vertex M 24-Point Continuous Monitor 4.3.2 Point Detail Display Area The Point Detail Area (see Figure 4-1) displays comprehensive information about each location. Touching a block in the System Display Area displays the current information about a location. Config File The configuration profile file name...
Page 85 Vertex M 24-Point Continuous Monitor Figure 4-2 is an image of the Point Detail section of the main Vertex display screen snapshot Analyzer The analyzer type Points / A point may be enabled but the alarm may be disabled Alarms...
Page 86: Function Buttons
Use Project functions to log in, log out, change area to access the following areas. passwords, update programs, restore the keyboard Menu - Perform runtime changes, flow and stop the project (exit Vertex M). calibration, maintenance, diagnostics and service functions, edit security settings and configure the system.
Page 87: Log In And Log Out
Vertex M 24-Point Continuous Monitor 4.4.1 Log In and Log Out The Vertex System will automatically log out any user after a period of inactivity. The default timeout period To protect the integrity of the system, the Vertex System is 8 hours. Authorized users may change the timeout classifies menus as either open or protected functions.
Page 88: Updating Program
OnScreen Keyboard Button 4.4.5 Stopping Project Use Stop Project to exit the Vertex M program. Touch Project and then Stop Project. Even though the Vertex M program is not running, individual analyzers continue to monitor and store data in their internal memory.
Page 89: Event History
Vertex M 24-Point Continuous Monitor 4.5.1 Event History An event is any action that the Vertex System is required to enter into the database. As events occur, the Vertex System stores the events in a database on the DAq PC. The default database format is Microsoft Access.
Page 90 Vertex M 24-Point Continuous Monitor Sort Options Sorting arranges data according to the values in one of the sort lists. The default sorting of events is chronologically with the most recent events first. If the data base is large, the sort may take a while.
Page 91 Vertex M 24-Point Continuous Monitor Print Prints current Display All Save query. Before Removes filtering. Saves current query to printing, note that an Access database. Event History can be quite long. The “total” figure shows the number of events. Figure 4-7. Event History...
Page 92 Vertex M 24-Point Continuous Monitor Date fields Defaults to current date. The default range is current date and the previous two weeks. Maximum Records Use to limit the number of Advance Filter Options records to display. Vertex will Use the Advance Filter Option display up to 10,000 records.
Page 93 Vertex M 24-Point Continuous Monitor Figure 4-9. Filter Options Section 4 - Operation 4-17...
Page 94 Select Filter Options-Modules Use to filter events based on specific points, analyzers or other hardware modules. Figure 4-10. Filter Options...
Page 95 Select User ID or Logging station Use to select a specific Vertex station or operator. Figure 4-11. Selecting Station or ID...
Page 96: Data Trend
Vertex M 24-Point Continuous Monitor 4.5.2 Data Trend Vertex plots gas concentration in the Data Trend window. You may choose multiple points to plot each point a different colored line on the graph. Data displayed in the graph can be either Stored data from the data log or Live (a continuous, real-time display, scrolling right to left).
Page 97 Vertex M 24-Point Continuous Monitor Use the Properties window (bottom right) to select locations and data to include in the Data Trend. Selection options include the Y axis data: points to display (to a maximum of 8), the data to display (live or stored) and the time span; and X axis data: one, some or all detection values.
Page 98: Optional Chemcam
Vertex M 24-Point Continuous Monitor 4.5.3 Optional ChemCam The Vertex ChemCam option provides a means to observe the stains on the last window of a Chemcassette ® tape. It consists of a small video camera located between the Chemcassette take up reel and the optic head.
Page 99 Vertex M 24-Point Continuous Monitor ChemCam Database Use the ChemCam Database tab to review, print or delete records in the ChemCam database. The Refresh button updates the window with records stored since the window was opened. Every record in the database includes the following: •...
Page 100: Event List
24-Point Continuous Monitor 4.5.4 Event List With the Event List, view and acknowledge active alarms and faults. Vertex M displays the newest event at the top of the list. Scroll through the events with the Back and More buttons. To select an event as the current event, touch the event. The current event will have a green border.
Page 101 Vertex M 24-Point Continuous Monitor Point Details Displays point detail for current selected point Event Help Displays the HTML help file designated for the point. Point help files are linked in the configuration utility. Data Trend Event History Opens the Data Trend...
Page 102: Menu Buttons
The event will occur after the timeout period set in the configuration window. Vertex M always displays the following items in the Run Time Options window. Section 4 - Operation...
Page 103 Vertex M 24-Point Continuous Monitor To Start or Stop an Analyzer from Monitoring Stopping an analyzer from monitoring prevents the system from triggering false alarms during testing and maintenance. 1. Choose Monitoring from the function buttons at the bottom of the screen.
Page 104 24-Point Continuous Monitor To Disable or Enable a Point Disabling a point prevents the system from triggering false alarms during testing and maintenance. Vertex M will not perform point specific fault checks on disabled points. 1. Choose Point Enable/Disable from the function buttons.
Page 105 Vertex M 24-Point Continuous Monitor 3. Choose Selected Point Only to enable / disable a single point Choose All Points for Location to enable / disable all of the points monitoring a location. 4. Touch Point Enable or Point Disable to change the state of the point.
Page 106 Vertex M 24-Point Continuous Monitor To Disable or Enable Alarms Disabling alarms prevents the system from triggering false alarms during testing and maintenance. 1. Select the analyzer and point from the keypad. The selected points turn dark gray on the keypad.
Page 107 Vertex M 24-Point Continuous Monitor Comment Event Use Comment Event to enter information about a point or analyzer that Vertex M would not automatically enter into the database. The comment is stored in Event History. 1. To enter a comment: 2.
Page 108: Flow Calibration
Vertex M 24-Point Continuous Monitor 4.6.2 Flow Calibration The Flow Calibration Window The Vertex M System requires exact flow rates and The Flow Calibration window consists of three parts: vacuum levels for accurate gas detection. Factors which • Flow display affect proper flow setup are sample line length, the type •...
Page 109 Vertex M 24-Point Continuous Monitor Section 4 - Operation 4-33...
Page 110 Vertex M 24-Point Continuous Monitor Flow Display The flow display shows information critical to verifying the flow rate for each point. Choose the analyzer from the selection pad in the upper right-hand corner. The eight points display their flow. Flow (cc/min)
Page 111 Vertex M 24-Point Continuous Monitor Proportional Value Range A vertical green bar displays the dynamic range over which the proportional valve can adjust the flow rate. Indicated numerically by Minimum Flow and Maximum Flow. Minimum Flow The minimum flow possible with the...
Page 112 Vertex M 24-Point Continuous Monitor Target Flow A horizontal red line indicates the target flow rate required by the Vertex M System for correct analysis. The target flow rate is 180 cc/min +/-5% (171-189 cc/min) Flow Rate A floating white box indicates the actual flow rate.
Page 113 Vertex M 24-Point Continuous Monitor Function Buttons Selection Pad Pump Alternate Toggles between pumps 1 and 2 Auto Balance Characterizes the control range of the proportional value Section 4 - Operation 4-37...
Page 114 130 seconds to complete. 6. If required, repeat for other analyzers. Note: If Vertex M cannot adjust the flow to the proper range (150 to 210 cc per minute at worst case condition) consult Honeywell Analytics service. Section 4 - Operation...
Page 115 Vertex M 24-Point Continuous Monitor Flow Calibration During Auto Balance Selection Pad Pump Alternate Toggles between pumps 1 and 2 Section 4 - Operation 4-39...
Page 116: Maintenance
Vertex M 24-Point Continuous Monitor 4.6.3 Maintenance Use the Maintenance window to: • Load and change Chemcassette tape. See Section 5.3.4 Change Chemcassette® Tape. ® • Change filters. See Section 5.3.3 Replace Filters. • Analyzer operation utilities (see the following pages)
Page 117: Diagnostics
The Profile ID is a unique number generated whenever the Vertex M Profile Management utility saves a configuration file. Vertex M stores the ID number in the DAq, the PLC and each analyzer. If the profile ID numbers do not match, a fault is generated and monitoring will not start.
Page 118 Profile ID - The Profile ID is a unique number generated whenever the Vertex M Profile Management utility saves a configuration file. Vertex M stores the ID number in the DAq, the PLC and each analyzer. If the profile ID numbers do not match, a fault is generated and monitoring will not start.
Page 119 Vertex M 24-Point Continuous Monitor PLC Information Displays the profile ID number in the PLC. Section 4 - Operation 4-43...
Page 120: Service
Use the Fault Test to verify operation of fault relays. Note: The fault test simulates an actual fault condition and the Vertex M System activates fault relays. Notify appropriate personnel that you plan to conduct a fault test. To conduct a fault test: 1.
Page 121 Use the alarm test to simulate a gas concentration for any analyzer. Note: The alarm test simulates an actual alarm condition and the Vertex M System activates all alarm relays. Notify ap- propriate personnel that you plan to conduct an alarm test.
Page 122 Vertex M 24-Point Continuous Monitor 4-20 mA Test Use the 4-20 mA test to test or calibrate external devices connected to the optional 4-20 mA PLC. Note: The 4-20 test generates an actual current output on the optional 4-20 mA PLC. Notify appropriate personnel that you plan to conduct a test.
Page 123: Security Access
Vertex M 24-Point Continuous Monitor 4.6.6 Security Access To protect against errors by personnel who are only authorized to install Chemcassettes ® , many of the Access to Vertex functions is granted according to a permission bits must be set to “off” as shown in brown permission list which is stored in an HMI user account.
Page 124: Configuration
Vertex M 24-Point Continuous Monitor 4.6.7 Configuration Before the Vertex M System can begin monitoring, you must create a configuration profile. Use the Configuration menu to create a new configuration profile or modify an existing profile. Keyboard Access Section 3.6 Configuration Utility...
Page 125: Maintenance
Vertex M 24-Point Continuous Monitor 5 Maintenance Vertex M Technical Handbook...
Page 126: Introduction
Vertex M 24-Point Continuous Monitor 5.1 Introduction 5.2 Maintenance Schedules This section descr ibes routine maintenance Perform maintenance following the schedule in procedures including general monitor maintenance and Table 5-1. See Appendix A Replacement and Chemcassette and pyrolyzer analyzer maintenance.
Page 127: Chemcassette ® Analyzer Maintenance
Universal Chemcassette and the pyrolyzer model ® The Vertex M Analyzer houses filters in a filter magazine. analyzers. Use the following procedure when replacing filters. 1. Set analyzer to idle in the Runtime Options window.
Page 128: Remove Filters
Figure 5-1. Analyzer Filter Door Note location of Acid Scrubber Filter Figure 5-3. Analyzer Filter Door Arrow must point downward Figure 5-2. Vertex M Filter Magazine Arrows must point downward 1. Open filter compartment by rotating the latch Figure 5-4. Vertex M Filters downwards and pulling handle down until door is at a 90˚...
Page 129: Change Chemcassette ® Tape
6. Touch the NEXT button to verify optics. The 2. Push analyzer into cabinet. tape advances as the Vertex M verifies the optics. 3. Return analyzer to monitor mode in Runtime 7. Push the analyzer into the cabinet.
Page 130: Replacing An Analyzer
Vertex M 24-Point Continuous Monitor 5.4 Replacing an Analyzer The Vertex M rack is designed for quick replacement of major components. You may replace both the Chemcassette and pyrolyzer analyzers while other analyzers continue to monitor. ® 5.4.1 Disconnecting Cables In steps 4 and 5 of the sequence that follows, you will need to disconnect the circular tubing harness and four electrical cables from the back of the analyzer.
Page 131: Remove Analyzer
Vertex M 24-Point Continuous Monitor 5.4.2 Remove Analyzer 1. Set analyzer to idle in the Runtime Options window. Touch Main Screen, Menu, Maintenance and then Analyzer Operation. Select the analyzer which you will replace. Touch Release Analyzer. 2. Open the front door and turn off power for the analyzer (and pyrolyzer switch if you are replacing a Pyrolyzer).
Page 132: Remove And Replace Pyrolyzer Filters
® nitrogen trifluoride by “cracking” or breaking it down with high temperatures. Heating nitrogen trifluoride converts it to hydrogen fluoride which the Vertex M pyrolyzer detects with a standard mineral acid Chemcassette ® The pyrolyzer heaters and associated control circuits...
Page 133: Replace Filters
24-Point Continuous Monitor 5.6 Remove and Install Pumps 5.5.2 Replace Filters The Vertex M System includes two vacuum pumps. One pump operates while the other is idle. You may replace a defective pump while the other pump continues to operate.
Page 134 Vertex M 24-Point Continuous Monitor Section 5 - Maintenance 5-10...
Page 135: Remove Pump
Vertex M 24-Point Continuous Monitor 5.6.1 Remove Pump CAUTION 1. Open lower cabinet door and remove filter. Operating the system with the exhaust fitting improperly 2. Turn thumbscrews counterclockwise to release and open pump enclosure door. installed or with one of the pumps removed can result in exposure to toxic gases from remote sampling areas.
Page 136: Install New Pump
2. Push pump completely into enclosure until Two replaceable modules provide power for the Vertex the release button locks into the bottom of the M System. A fully populated Vertex M will operate with enclosure. one supply. You may replace the defective supply while the system continues to monitor.
Page 137: Replace Supply
Vertex M 24-Point Continuous Monitor 5.9 PLC Module Battery Backup Check 5.7.2 Replace Supply 1. Insert new supply in housing. 1. For status of battery locate indicator as shown in photo on the left. 2. Verify handle is on the left of the power supply.
Page 138: File Maintenance
2. Make an offline backup copy of the files listed below in . The following files on the Vertex M should be copied to either a backup location on your local area network, removable media or a CD-R/CD-RW disk.
Page 139: Optics Cleaning
ChemCam. C:\HMI\ ChemCam Database mdb * ChemCam * Required if stored locally on the Vertex M System NOTE: Database files are size limited to a maximum of 2Gb. Table 5-2. File Locations 5.11 Optics Cleaning Clean Chemcassette optics annually or whenever ®...
Page 140 Vertex M 24-Point Continuous Monitor Section 5 - Maintenance 5-16...
Page 141: Troubleshooting
6 Troubleshooting Vertex M Technical Handbook...
Page 142: Introduction
Maintenance and instrument faults are Vertex M System self-diagnostic messages. They alert you to operation abnormalities by displaying a message with a brief description. The Vertex M System also stores the faults in the event history list. Also included in this chapter are information events which are records of non-fault activities that may aid in troubleshooting.
Page 143 LCD Display Symptom Problem Recovery Faulty connection at DAq Check connection at SVGA connector on back of DAq Faulty connection at display Check connection on back of display Check power cable between power distribution box and display No power to display power supply No display Touch the LCD screen...
Page 144 Check cable connection to Ethernet port Note: Use only the Ethernet connection on the back of the data Incorrect network connection acquisition computer. The Ethernet hub in the Vertex M System Vertex M not appearing is only for Vertex M internal use.
Page 145: Maintenance Faults
6.3 Maintenance Faults A maintenance fault indicates the Vertex M System requires attention but is continuing to monitor. When a maintenance fault occurs, the following actions take place within the Vertex M System: • The LED indicator flashes yellow on the analyzer with the fault. See Table 6-1.
Page 146 Relieve/reduce pressure PRESSURE Pressure between sampling atmospheric pressure location and monitor while in idle Transducer error Calibration error Contact Honeywell Analytics Service Defective sensor Contact Honeywell Analytics Service Offset incorrect Contact Honeywell Analytics Service FLOW ADJ ERR High Flow After cc/min.
Page 147 Replace all orifices with flow orifices installed 0.015 in orifices (p/n 1290K0009 per Analyzer) Check valve on inactive Replace check valve pump leaking Contact Honeywell Analytics Service OPTICS MAINT Optics Drive Drive LED drive required to set Clean optics High-Cleaning...
Page 148 Replace with supply SUPPLY Fail/missing available 0060-0020 BAD OPTICS Optics Sum of error 1.0: Front block reads Cold Environment Relocate Vertex M TEMP Temperature codes 1.0 to <0˚C Out Of Range 64.0 2.0: Front block reads Electronic problem Replace front optics block >60˚C...
Page 149 Ambient pressure at Revise installation the optional Line Integrity sampled point differs Test from Vertex M exhaust Disable LIT for affected by more than 0.3 in Hg point (1 KPa) Check valve not seating Replace check valve Coordination Error code 1.0...
Page 150 Event Event List Desc. Event History Data Field Problem Possible Cause Recovery Number (Short) Description AUTOBALANCE Flow No. of Failed Detailed failures can be determined by the data from the accompanying info FAIL Autobalance Attempts event(s) by using the table below. Failed Anomaly encountered Repeat Auto balance...
Page 151: Instrument Faults
An instrument fault indicates a loss of monitoring on one or more points. When an instrument fault occurs, the following actions take place within the Vertex M System: The LED indicator flashes yellow on the analyzer with the fault. See Table 6-1.
Page 152 FAILURE optics reading Contact Honeywell exceeded limits service Optics board defective Contact Honeywell service Sensor interface defective Contact Honeywell service Optics LED not properly Perform Load CC calibrated Operation to recalibrate GAS TABLE Gas Table Error Gas table corrupt or...
Page 153 6 in Hg failed - 1 or 2 vacuum while Fault 112 Circuit breaker tripped Circuit breakers are self active. resetting. Contact Honeywell Service LOSS OF Loss of Flow cc/min. Flow less than 180 cc/ Perform Auto Balance FLOW min.
Page 154 Event Event List Event History Data Field Problem Possible Cause Recovery Number Desc. (Short) Description NO PYRO No Pyrolyzer No mains power at Internal thermal fuse Check cooling fan, MAINS PWR Mains Power points 5-8 opened replace thermal fuse No mains power at points 1-4 No mains power at all 8 Pyro mains switch not on...
Page 155 Software anomaly. cable connection on failure optics block. Defective optics block. the sensor board. Cycle power to analyzer. Contact Honeywell service. OPTICS REF Optics reference Reference The signal detected at Degraded optics block. Contact Honeywell service. FAIL...
Page 156 OPT REF ADJ Optics reference Error code Optics block self- Cycle power to analyzer. TIMEOUT adjustment adjustment timeout. Contact Honeywell service. timeout COM AZ # # OPC To Az ## Analyzer not Analyzer powered down Check switch on power BROKEN...
Page 157: Information Events
6.5 Information Events The Vertex M System enters informational and other non-fault events into the event history database. These do not require any action by the user. Use the event history to check the status of the monitor. Event Type In History...
Page 158 Event Type In History Event History Message Possible Cause INFO LED Drive Adjusted Load CC INFO Monitoring stopped for no pts All points disabled by faults INFO New Chemcassette Was Installed User initiated action INFO New Sector Started Normal maintenance INFO Optics Verified Successfully Load CC...
Page 159: Lit-Related Informational Events
Note: If additional or replacement Vertex M Analyzers are purchased without specifying the LIT option, no faults will be generated for the lack of the option in the new analyzer. However, an “INFO” message will be logged in the Event History each time the LIT option is invoked.
Page 160: Manual Analyzer Override
6.6 Manual Analyzer Override files can slow down the response of the DAq. To confirm a non-responsive DAq as opposed to frozen/locked-up, The Vertex M Analyzer is equipped with a “Manual check the clock located in the upper right hand corner Override” button...
Page 161 Analyzer Removal Figure 6-3. Vertex M Analyzer Removal Key and Slot Location 2. Locate the Ethernet cable on the rear panel and disconnect it. Analyzer Communications (Ethernet) Figure 6-4. Analyzer Ethernet Communication Cable Location Section 6 - Troubleshooting 6-21...
Page 162 3. Open the side of the Analyzer by unscrewing the 4 thumbscrews at the top of the left side. Figure 6-5. Analyzer 4. Approximately 20 seconds after the Ethernet Cable has been disconnected, the Analyzer will recognize that it has lost communications with the DAq and activate the “Manual Override” button shown in Figure 6-1.
Page 163 time in millesconds Alarm Fault Mon State State State none black green maintenance amber black idle instrument amber black black black none green black pyrolyzer m or i green black amber warmup green black none green black maintenance amber green monitoring instrument amber...
Page 164 Section 6 - Troubleshooting 6-24...
Page 165 Vertex M 24-Point Continuous Monitor A Installation Drawings Vertex M Technical Handbook...
Page 166: Installation Drawings
Vertex M 24-Point Continuous Monitor A.1 Introduction Appendix A - Installation Drawings...
Page 167: Floor Space Requirements
Vertex M 24-Point Continuous Monitor A.2 Floor Space Requirements Appendix A - Installation Drawings...
Page 168: General Considerations And Cooling
Vertex M 24-Point Continuous Monitor A.3 General Considerations and Cooling Appendix A - Installation Drawings...
Page 169: General Wiring
Vertex M 24-Point Continuous Monitor A.4 General Wiring Appendix A - Installation Drawings...
Page 170 Vertex M 24-Point Continuous Monitor Appendix A - Installation Drawings...
Page 171: 4-Port Manifold Option
Vertex M 24-Point Continuous Monitor A.5 4-Port Manifold Option Appendix A - Installation Drawings...
Page 172: Floor Mounting Option
Vertex M 24-Point Continuous Monitor A.6 Floor Mounting Option Appendix A - Installation Drawings...
Page 173 Vertex M 24-Point Continuous Monitor Appendix A - Installation Drawings...
Page 174 Vertex M 24-Point Continuous Monitor A Specifications Vertex M Technical Handbook...
Page 175: Specifications
Nitrogen Dioxide Nitrogen Trifluoride Filters have an arrow on the side of the filter pointing COCl Phosgene in the direction of airflow toward the Vertex M system. Phosphine Replacement of filters is site dependent. Silane Sulfur Dioxide Filter A - P/N 780248...
Page 176: Physical Dimensions
All relays are undefined by default, and must • Pyrolyzer Az: 48 lbs. (22 kg) be configured as required. See Appendix E • Empty Vertex M Rack: 457 lbs. (207 kg) Optional Relay Specifications. Tubing dimensions: • Optional 4-20 mA analog: 0-500 ohms •...
Page 177: Nominal Transport Times
Vertex M 24-Point Continuous Monitor A.4 Nominal Transport Times The following table shows the time required for samples to move from the sampling point to the Vertex M system for various lengths of sample lines. O.D. 0.25 in. Outside Diameter Tubing I.D.
Page 178 Vertex M 24-Point Continuous Monitor A Detectable Gases Vertex M Technical Handbook...
Page 179: Detectable Gases
Vertex M 24-Point Continuous Monitor A.1 Detectable Gases Vertex M System Chemcassette analyzers are continuous monitoring instruments. The initial analysis period ® listed in Table C-1 varies based on the programmed alarm levels. This period is valid only after the system pulls a new Chemcassette window.
Page 180: Boron Trifluoride
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) <20 sec...
Page 181: Chlorine Dioxide
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 30-199 ppb...
Page 182: Fluorine
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 0.1-0.9 ppm Fluorine 0.06...
Page 183: Hydrogen Chloride
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 0.5-9.9 ppm Hydrogen Chloride 10-19.9 ppm...
Page 184: Hydrogen Iodide
Low Level TWA) 400-2000 ppb *Due to U.S. Government regulations, this range may be subject to restrictions requiring special licensing for certain countries outside North America. Contact Honeywell Analytics for eligibility information. 0.2-1.4 ppm Hydrogen Iodide None 0.2 ppm 0.1 ppm...
Page 185: Nitrogen Dioxide
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 2-9.9 ppm <20 sec...
Page 186: Phosgene
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 1-9.9 ppm Nitrogen Trifluoride XP 10-19.9 ppm...
Page 187: Silane
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) Phosphine XP4...
Page 188: Sulfur Dioxide
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) 0.05-2.49 ppm 2.5-4.99 ppm...
Page 189: Tetrakis Dimethylamino
Vertex M 24-Point Continuous Monitor Time to 1 TLV Initial Default Default (Alarm @ 2 TLV Chemcassette Analysis Gas Name 1 Alarm Alarm Range Alarm Setting Concentration Part Period Level 1 Level 2 10-ft. Sample Number (second) Line) Tetrakis Dimethylamino 0.1-0.4 ppm...
Page 190 Vertex M 24-Point Continuous Monitor A Replacement and Consumable Items Vertex M Technical Handbook...
Page 191: Replacement And Consumable Items
Vertex M 24-Point Continuous Monitor A.1 Consumables A.1.4 Pyrolyzer Filters A.1.1 Chemcassettes ® Freon Filter (package of 4) 1874-0139 A.1.5 Rack Filters Aliphatic Amines NH3 1295-0221 Cl2-Iii Oxidizers 1295-0224 Glass Fiber Filter (pump module) 0235-1186 Fluorine 1295-0220 Hydrides 1295-0300 A.2 Printed Circuit Boards...
Page 192: Pyrolyzers
Vertex M 24-Point Continuous Monitor A.3.2 Pyrolyzers Hot Swappable 24VDC Power Supply 0060-0020 Microtube Assembly A.3.4 Pump Modules 1295A0235 (one point, for pyrolyzer Pts 1 - 4) Microtube Assembly Pump Assy, 220/230VAC 1290A0059 1295A0236 (one point, for pyrolyzer Pts 5 - 8)
Page 193 Vertex M 24-Point Continuous Monitor Appendix A - Replacement and Consumable Items...
Page 194 Vertex M 24-Point Continuous Monitor A Optional Relay Specifications Vertex M Technical Handbook...
Page 195: Optional Relay Specifications
Vertex M 24-Point Continuous Monitor A.1 Relay Output Contacts Maximum Amperes Amperes Volt-Amperes Volts Continuous Relay output contacts: via PLC, normally open Make Break Make Break (form A). Available in 32 and 64 contacts, both are user 240 VAC 7.5A 0.75A...
Page 196: Default Relay Assignments
Individual Relay Card Part Number: 0185-0053 levels. Com for 0-7 A.3.1 Introduction By default, the Vertex M reserves the first 2 contacts for faults. You may associate any remaining relay contacts with points in any analyzer. See Section 3.6.3 Set...
Page 197: Terminal Assignment Of 1746-Ox8 Relay Module
Vertex M 24-Point Continuous Monitor A.3.4 Terminal Assignment of 1746-OX8 Relay Module Option Part Number: 1290-0077 Individual Relay Card Part Number: 0185-0090 Appendix A - Optional Relay Specifications...
Page 198 Vertex M 24-Point Continuous Monitor A Network Interface and Options Vertex M Technical Handbook...
Page 199 OLE for Process Control (OPC) Interface. See Section A.2 OLE for Process Control (OPC) Interface. Options: The Vertex M can be fitted with any one of six optional fieldbus interfaces as summarized in Table F-1. Table A-1. Vertex M Fieldbus Options Honeywell...
Page 200: Network Interface And Options
The primary method of alarm and fault annunciation application will need to include the following information. used by the Vertex M Gas analyzer relies on the Allen More information on OPC and client application is Bradley SLC500 PLC system installed in the base available at www.opcfoundation.org.
Page 201 Vertex M 24-Point Continuous Monitor Table A-3. Tag Names Recommended Tag Name Folder Tag Count for most HMI Value Interpretation / Description Format systems Integer, 1 byte long Status 0 = No alarm Alarm ##_1 1 = Warning 2 = Alarm 1...
Page 202 Vertex M 24-Point Continuous Monitor Table F-3. Tag Names (continued) Recommended Tag Name Folder Tag Count for most HMI Value Interpretation / Description Format systems String containing the fault number and long fault description for the most recent Pt fault. The contents of this item, the corresponding short...
Page 203 Vertex M 24-Point Continuous Monitor Table F-3. Tag Names (continued) Recommended Tag Name Folder Tag Count for most HMI Value Interpretation / Description Format systems Flow Control DtoA For HA internal use only Flow Integer sample point flow in cc/minute Pressure Float32, point sample pressure in inches Hg, (usually approx.
Page 204 Vertex M 24-Point Continuous Monitor Table F-3. Tag Names (continued) Recommended Tag Name Folder Tag Count for most HMI Value Interpretation / Description Format systems Unsigned integer Status 0 = No fault 1 = Maintenance Fault 2 = Instrument Fault...
Page 205 String, either “ppm” “ppb” or “mg/m3” Note: The Vertex M uses the same OPC server as the Vertex. Thus numerous OPC tags exist for non-existent analyz- ers. Tags for points greater than 24 or analyzers greater than 3 are not populated and invalid.
Page 206: Data Values Common To Fieldbus Networks
Vertex M 24-Point Continuous Monitor A.3 Data Values Common to Fieldbus A.3.2 Concentrations Finally, the concentration information is reported as Networks one 16-bit word for each point as shown in Table A-5. All six optional fieldbus networks report alarm, fault Table A-5.
Page 207: Heartbeat
0.5 TLV and 18723 counts corresponds to 1.0 TLV by the internal PLC. In the Vertex M the modules function default. This can be altered by editing the configuration as slaves only, although the hardware may be capable...
Page 208: Data Map
24-Point Continuous Monitor A.4 Data Map Table F-6. Fieldbus Data Addresses (Except LonWorks) continued Five of the optional fieldbusses (all except LonWorks) report the status of the Vertex M in the same 122 Word Address Word Address word (244 byte) format which is listed in Table F-5. If...
Page 209: Profibus Option (P/N 1295-275
Table A-4. The network management tool will need a .GSE file to describe every slave on the network. The vertex.gse file can be copied from any Vertex M at c:\hmi\Profibus\vertex.gse. A.5.1 Termination The Profibus adapter PCB assembly shown in Figure...
Page 210 Vertex M 24-Point Continuous Monitor Table A-7. Procedure 1—Changing Profibus Configuration F1.1. Obtain a computer with free RS232 serial port. F1.2. Start a terminal emulator program such as HyperTerminal F1.3. Configure the terminal emulator for 38400,N,8,1 F1.4. Connect the provided DB9 cable from the selected port on the computer to the top DB9 connector on the Profibus card.
Page 211: Devicenet Interface (P/N 1295-0329
A-5. The interpretation of the data is in Technical Information on the Allen-Bradley 1747-SDN Table A-3 Table A-4. DeviceNet interface which is used in the Vertex M is Successful commissioning of a ControlNet Networks available at http://literature.rockwellautomation.com/ requires the use of a network management tool. Such...
Page 212: Df1 Interface (P/N1295-0343
Technical information on the ProSoft Technology MVI46-DFCM interface which is used in the Vertex M Figure A-4. DF1 Connection to RJ45 Socket can be found at http://www.prosoft-technology.com. The pinout of the DF1 port is as follows: The baud rate and address of the DF1 interface are set using the configuration profile utility as described Table A-8.
Page 213: Modbus Plus Interface (P/N 1295-0330
1 to 64. other components. This is a purple box mounted below the PLC in the rear of the Vertex M rack. The interface The ProSoft website contains the MVI46s-MBP User can be operated in either Polled Mode or Bind Mode.
Page 214: Modbus/Tcp (P/N1295-0520
This interface uses ProSoft-Technology MVI46- 1. An external personal computer with Microsoft Windows 2000 or later operating system and MNET hardware. In the Vertex M, this interface is always an unused serial port. a TCP server, never a client. For more information see www.prosoft-technology.com...
Page 215 Vertex M 24-Point Continuous Monitor This procedure is used to set the IP Address Procedure 1 1. Determine the desired IP address, subnet mask, and default gateway. Usually a network administrator will assign these numbers. Note that the MVI46-MNET will not function as a client for the DHCP protocol.
Page 216 If an error occurs, repeat this procedure. 7. The 122 words of Vertex M status which are listed in Table F-5 may be viewed on the 13. Verify that HyperTerminal displays: diagnostic port. These are mapped as registers FILE TRANSFERRED FROM PC UNIT..THE...
Page 217: Ethernet/Cip (P/N1295-0519
WARNING It is essential that Ethernet/CIP clients which communicate with the Vertex M monitor the “Heartbeat” byte in word 40. This is because the MVI46-DFNT will continue to communicate if the Vertex M PLC ceases to run. External automation equipment must be programmed to treat a failure of the heartbeat to increment as a complete loss of gas detection.
Page 218: Configuring The Ip Address
Note: If there are not sufficient licenses or if all licenses networks is non-deterministic and can become are in use, you will not be able to access the Vertex M large if the network is heavily loaded. remotely. Changing this number is beyond the scope 3.
Page 219: Basic Desktop Station Setup
“ipconfig” command desktop to view Niagara Racks. If this is not installed as shown in Figure 2. Note that the Vertex M has two on your PC, you must install it to use the virtual Vertex Ethernet interfaces: the address of “External_Ethernet”...
Page 220 24-Point Continuous Monitor Figure A-11. Starting Niagara Remote Display Adding the Vertex M IP address to the IE Favorites folder saves time. The Vertex M HMI will appear in Internet Explorer as shown in Figure F-12. The virtual Vertex M interface...
Page 221 Vertex M 24-Point Continuous Monitor Figure A-12. Vertex M HMI in Internet Explorer Appendix A - Network Interface and Options F-24...
Page 222: Full Desktop Station Setup
Configuration Editor and Chemcassette installation Windows Accounts. screens are not available remotely. Vertex M Client is distributed on the Vertex M Application A.13.4.3 Create Group “VertexDCOMUsers” Software CD. This group is needed to facilitate acceptance of the Remote configuration is possible but requires changing credentials of the two computers.
Page 223 Vertex M 24-Point Continuous Monitor Figure A-13. Create Group “VertexDCOMUsers” Appendix A - Network Interface and Options F-26...
Page 224: Disable Windows Firewall
Vertex M 24-Point Continuous Monitor A.13.4.4 Disable Windows Firewall This is described in Section A.13.4.6 Windows Firewall. A.13.4.5 Configure DCOM Remote operation of the Chemcam Viewer and the Configuration Editor requires numerous changes to Windows XP using the dcomcnfg program: •...
Page 225 Vertex M 24-Point Continuous Monitor Table A-12 contains the programs that need security modifications and which modifications are required.Table A-11 contains the explanations for the abbreviations used in Table A-12. Table A-11. Category Symbols Symbol Label APED Access Permissions / < Edit Default > button APEL Access Permissions / <...
Page 226 Vertex M 24-Point Continuous Monitor Figure A-18. Custom Permissions Appendix A - Network Interface and Options F-29...
Page 227 Vertex M 24-Point Continuous Monitor Table A-12. Program List for Security Modifications Program Category (See Table F-11) Object Value Administrators, ANONYMOUS LOGON, Everyone, Guests, APED INTERACTIVE, all “Allow” NETWORK, SYSTEM, Users, VertexDCOMUsers ANONYMOUS LOGON, Everyone, APEL Interactive, all “Allow” Network,...
Page 228 Vertex M 24-Point Continuous Monitor “The interactive Which user account do you want to user” (Note this Identify use to run this application? setting not needed for OPCEnum.) General Authentication level “None” Launch and Activation Guest all “Allow” Permissions/ All pre-existing objects all “Allow”...
Page 229: Windows Firewall
Vertex M 24-Point Continuous Monitor A.13.4.6 Windows Firewall The Windows Firewall must be turned off: Click on Start in the Windows taskbar • • Select Settings and then Control Panel from the menu. Figure A-19. Control Panel • Double click on Windows Firewall and click to select Off (not recommended), as shown in Figure F-19.
Page 230: Create Matching Windows Accounts
Microsoft Windows security requires that matching accounts exist on both the rack and the desktop to provide the necessary credentials. Every Vertex M rack ships with an account named “Honeywell Analytics” and the password “vertex” One way to provide the matching accounts is to create a similar account on the desktop.
Page 231: Demonstrating Remote Opc Communication
This procedure describes how to set up OPC 9. Create an account on the external computer communications from a Vertex M rack and an external “Honeywell Analytics” with the password of Microsoft Windows computer. Some of the required “vertex”.
Page 232: Demonstration With Matrikon Opc Explorer
12. Select an item from the list of Available 6. To communicate with a Niagara rack, Items (as shown underlined in pink in the fill in the server name with “Honeywell. MatrikonOPC Explorer (g1) window. VertexOPCServerDA.1” as shown below. To communicate with an RSView rack, us a server 13.
Page 233 Vertex M 24-Point Continuous Monitor Matrikon OPC Explorer window Figure A-23. Matrikon OPC Explorer Window Appendix A - Network Interface and Options F-36...
Page 234 Vertex M 24-Point Continuous Monitor MatrikonOPC Explorer (g1) window Figure A-24. MatrikonOPC Explorer (g1) Appendix A - Network Interface and Options F-37...
Page 235: Demonstration With Daclient
Vertex M 24-Point Continuous Monitor A.14.3 Demonstration with DAClient 2. Select a group name such as the default “Group1”. Note: 3. Select tags by double-clicking on the bottom- DAClient is a free OPC demonstration program from Rockwell Software. right box of the “Add Item” form as shown in Figure F-25.
Page 236 Vertex M 24-Point Continuous Monitor 4. When all desired tags have been added, click OK to close the window 5. Verify that data appears with Current Quality set to “Good” as shown. Figure A-27. RSI Data Client Appendix A - Network Interface and Options...
Page 237 Vertex M 24-Point Continuous Monitor A 4-20mA Analog Output Option Vertex M Technical Handbook...
Page 238: 4-20Ma Analog Output Option
The application provides an analog output option for the and all other slots populated with Spectrum Controls Vertex M by utilizing a second SLC 5/03 PLC rack. This 1746sc-INO4i modules. No configuration is needed rack communicates with the primary PLC via the DF1 on these modules, however there is a user settable Fieldbus option.
Page 239: Operational Description
Vertex M 24-Point Continuous Monitor A.4 Operational Description Channel mapping is defined by the following Table G-1. The analog outputs on the secondary PLC will mirror the corresponding Fieldbus concentration register as Table A-1. defined in Section F.3.2 Concentrations. This section...
Page 240 Vertex M 24-Point Continuous Monitor Appendix A - 4-20mA Analog Output Option...
Page 241 Vertex M 24-Point Continuous Monitor A Line Integrity Test Option Vertex M Technical Handbook...
Page 242: Line Integrity Test Option
24-Point Continuous Monitor Honeywell Analytics now offers the optional capability Note: to check for leaks in Vertex M sample lines. Analyzers In this document all pressures are given in inches equipped with option 1295-0510 detect a pneumatic of mercury. This may be converted to kilopascals by signal from valves installed at the end of the sample multiplying by 3.38.
Page 243 The use of external filters is mandatory with Vertex that up to three LI tests can be performed per day. As M LIT as it is with all Vertex M points. Appendix B with previous software, the time of the TWA can be Specifications Section B.2 Filter Compatibility...
Page 244 Vertex M 24-Point Continuous Monitor Figure A-3. Configuration Editor New Button Figure A-2. LIT Access Pressing the “Line Integrity Test” button shown in Figure causes the form shown in Figure H-4 to appear. The three times displayed on the left of the new tabsheet indicate the TWA times.
Page 245 Vertex M 24-Point Continuous Monitor LIT Access from the HMI The HMI has two buttons. 1. Two buttons in the Authorized Service screen as shown in Figure H-3. When the associated analyzer is in Monitor mode this will appear as...
Page 246 The Vertex M is also capable of five new informational events as listed in Section 6.5 Information Events.
Page 247 Vertex M 24-Point Continuous Monitor A Warranty Statement Vertex M Technical Handbook...
Page 248: Warranty Statement
System that is certified to ISO 9001. As such, this monitor (including the pump) is warranted Honeywell Analytics shall not be liable for any loss or under proper use, to the original end-user purchaser, damage whatsoever or howsoever occasioned which...
Page 249: Chemcassette ® Warranty
Honeywell Analytics’ Chemcassettes have been installed and used in ® Honeywell Analytics’ monitors. Honeywell Analytics reserves the right to change this policy at any time. Contact Honeywell Analytics for the most current warranty information. Chemcassette Warranty ® All Chemcassettes are warranted for a period not to ®...
Page 250 Vertex M 24-Point Continuous Monitor Appendix A - Warranty Statement...

Honeywell Vertex M Technical Handbook

Table of Contents

Introduction

Installation

Startup

Operation

Maintenance

Troubleshooting

Installation Drawings

A.1 Introduction

Specifications

Appendix B Consists of the Following Sections

A.1 Introduction

Vertex M 24-Point Continuous Monitor

A.2 Filter Compatibility

Quick Links

Chapters

Related Manuals for Honeywell Vertex M

Summary of Contents for Honeywell Vertex M
