Machining the workpiece
7.12 Display G and auxiliary functions
Further information
Additional information on the contour / orientation tolerance is provided in the Basic Functions
Function Manual.
Procedure
7.12.4
Auxiliary functions
Auxiliary functions include M and H functions preprogrammed by the machine manufacturer,
which transfer parameters to the PLC to trigger reactions defined by the manufacturer.
Displayed auxiliary functions
Up to five current M functions and three H functions are displayed in the "Auxiliary Functions"
window.
Procedure
...
184
1.
Select the "Machine" operating area
2.
Press the <JOG>, <MDI> or <AUTO> key.
3.
Press the ">>" and "All G functions" softkeys.
The "G Functions" window is opened.
1.
Select the "Machine" operating area.
2.
Press the <JOG>, <MDA> or <AUTO> key.
Operating Manual, 07/2021, 6FC5398-6AP40-6BA4
Universal
