Setting up the machine

5.9 MDA

5.9 MDA
In "MDI" mode (Manual Data Input mode), you can enter G-code commands or standard cycles
block-by-block and immediately execute them for setting up the machine.
You have the option of loading an MDI program or a standard program with the standard cycles
directly into the MDI buffer from the program manager; you can subsequently then edit it.
You can save programs, generated or modified in the MDI working window, in the program
manager, e.g. in a directory specifically created for the purpose.
5.9.1

Loading an MDA program from the Program Manager

Procedure
120
Machine manufacturer
Please observe the information provided by the machine manufacturer.
1. Select the "Machine" operating area.
2. Press the <MDA> key.
The MDI editor opens.
3. Press the "Load MDI" softkey.
The "Load into MDI" window opens. It shows you a view of the program
manager.
4. Position the cursor to the corresponding storage location, press the
"Search" softkey and enter the required search term in the search dialog if
you wish to search for a specific file.
Note: The place holders "*" (replaces any character string) and "?" (repla‐
ces any character) make it easier for you to perform a search.
5. Select the program that you would like to edit or execute in the MDI
window.
6. Press the "OK" softkey.
The window closes and the program is ready for operation.
