Summary of Contents for Honeywell Fire-Lite Alarms MS-9600
Page 1
PN: 51335:E1 ECN 08-116 Fire Alarm Control Panel MS-9600/MS-9600E IMPORTANT! The SLC Manual Document #51309 must be referenced in addition to this manual when installing or servicing the Fire Alarm Control Panel. Document #51335 2/14/08 Rev:...
Page 2
While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of age of flammable materials, etc.). smoke detectors, heat detectors, manual pull stations, Heat detectors do not sense particles of combustion and audible warning devices, and a fire alarm control panel with alarm only when heat on their sensors increases at a...
Page 3
Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected to sources of power before servicing.
Page 7
Table of Contents 3.6.10: Password Change ..........................99 3.6.11: Clear Program ..........................100 3.6.12: Program Check..........................101 3.7: Maintenance Programming Level .......................103 3.7.1: Disable Point .............................104 3.7.2: History...............................105 3.7.3: Program Check..........................106 3.7.4: Walktest.............................107 3.7.5: System ...............................107 3.7.6: Zone Setup ............................109 SECTION 4: Operating Instructions ........................111 4.1: Panel Control Buttons ..........................111 4.1.1: Acknowledge/Step ..........................111 4.1.2: Alarm Silence............................111...
Page 8
Table of Contents 4.22.13: Service Terminal..........................132 4.22.14: Printer/PC ............................132 4.22.15: Print ...............................133 4.22.16: Time-Date............................135 SECTION 5: Power Supply Calculations ......................136 5.1: Overview ..............................136 5.2: Calculating the AC Branch Circuit......................136 5.3: Calculating the System Current Draw......................137 5.3.1: Overview ............................137 5.3.2: How to Use Table 5.3 on page 138 to Calculate System Current Draw ...........137 5.4: Calculating the Battery Size ........................139 5.4.1: NFPA Battery Requirements ......................139 5.4.2: Selecting and Locating Batteries.......................139...
Page 9
It is imperative that the installer understand the requirements of the Authority Having Jurisdiction (AHJ) and be familiar with the standards set forth by the following regulatory agencies: • Underwriters Laboratories Standards • NFPA 72 National Fire Alarm Code • CAN/ULC - S527-99 Standard for Control Units for Fire Alarm Systems Before proceeding, the installer should be familiar with the following documents.
Product Description Inventory Product Description SECTION 1 The Fire•Lite MS-9600 is a compact, cost effective, intelligent addressable FACP (Fire Alarm Control Panel) with an extensive list of powerful features. The combination of Fire•Lite’s newer series devices and legacy 300 Series devices, along with the MS-9600 FACP, offer the latest in fire protection technology.
Page 13
Features and Options Product Description • PAS (Positive Alarm Sequence) and Pre-signal per point (NFPA 72 compliant) • Annunciators: ACM Series-LED Zone Annunciators LDM Graphic Annunciator Series LCD-80F Liquid Crystal Display point annunciator ACM-8RF Relay Module • Silence inhibit timer option per NAC •...
Product Description Controls and Indicators 1.4 Controls and Indicators LCD Display The FACP uses an 80-character (4 FIRE-LITE ALARMS INC lines X 20 characters) high viewing SYSTEM ALL NORMAL angle LCD display. The display includes a long life LED backlight 10:00A 020102 that remains illuminated.
Circuits Product Description 1.5 Circuits SLC Communication Loop One SLC loop is provided standard on the FACP main circuit board. A second SLC loop is available by plugging the optional SLC module into connector J3 on the main circuit board. SLC loops, configurable for NFPA Style 4, 6 or 7, provide communication to addressable detectors, monitor (initiating device) and control (output device) modules.
Product Description Components Cabinet The MS-9600 cabinet is red with a navy blue front overlay. The backbox provides space for two batteries (up to 18 Amp Hour). Ample knockouts are provided for system wiring. Also included is a standard dress panel, which mounts to the inside of the cabinet (required by ULC for Canadian applications).
Components Product Description 1.6.2 Intelligent Addressable Modules: Newer Series The newer series of Control Modules and Monitor Modules provide an interface between the control panel and conventional notification and initiating devices. Each module can be set to respond to an address with built-in rotary switches with the ability to select up to 159 addresses (a tab on the address switch must be broken off to use addresses 100-159).
Product Description Optional Modules 1.6.3 300 Series Intelligent Addressable Devices Fire•Lite’s 300 Series Intelligent Addressable Devices are fully compatible with the MS-9600 FACP. The devices must be configured for CLIP Mode operation if the control panel is installed in an existing system with 300 Series devices. The address of 300 Series devices cannot be set above 99.
Accessories Product Description 1.8 Accessories 1.8.1 PK-CD Programming Utility The PK-CD Programming Utility can be used to program an MS-9600 directly from most IBM compatible computers, including laptops and portables, equipped with a serial port. MS-9600 program files can also be created and stored on the PC and then downloaded to the control panel.
Product Description Accessories 1.8.4 Battery Charger 1.8.4.1 CHG-75 Battery Charger The CHG-75 is capable of charging up to 75 AH lead-acid batteries with the MS-9600 FACP. The FACP battery charger must be disabled when using the CHG-75. The charger and up to 26 AH batteries can be housed in the Fire•Lite BB-26 battery box.
Getting Started Product Description LCD-80F Remote Fire Annunciator The LCD-80F annunciator is a compact 80-character backlit LCD remote fire annunciator that is capable of displaying English language text. It mimics the display on the control panel and will annunciate device type, point alarm, trouble or supervisory condition, zone assignment plus any custom alpha labels programmed into the FACP.
Installation Mounting Installation SECTION 2 The cabinet may be either semi-flush or surface mounted. The cabinet mounts using two key slots and two 0.250” (6.35 mm) diameter holes located in the backbox. The key slots are located at the top of the backbox and the two securing holes at the bottom. Carefully unpack the system and check for shipping damage.
Page 25
Mounting Installation 4.45 cm 5.1 cm 1.75“ 1.75“ 2.00“ 2.00“ 2.00“ 2.00“ 2.00“ 2.00“ 1.50“ (3.81 cm) 3.79 cm 15.5“ (39.37 cm) 3.81 cm 1.62“ (4.11 cm) 1.49“ 12.00“ (30.48 cm) 1.50“ 4.1 cm 4.1cm 1.453“ (3.69 cm) 1.62“ 1.62“ 10.0“...
Page 26
Installation Mounting Depth = 4.37" (11.1 cm) Depth = Door = 15.78" (40.08 cm) 4.425" Backbox = 15.5" (39.37 cm) (11.24 cm) Door = 18.67" (47.43 cm) Backbox = 18.5" (47.0 cm) Left Side Right Side Bottom 18.620" (47.3 cm) Depth = 4.75"...
Power Installation 2.2 Power WARNING: Several different sources of power can be connected to this panel. Disconnect all sources of power before servicing. The panel and associated equipment may be damaged by removing and/or inserting cards, modules or interconnecting cables while this unit is energized. 2.2.1 AC Power and Earth Ground Connection Primary power required for the FACP is 120 VAC, 50/60 Hz, 3.2 amps for the MS-9600 or 220/240 VAC, 50/60 Hz, 1.6...
Installation Relays 2.3 Relays The FACP provides two programmable Form-C relays and one fixed fail-safe Form-C trouble relay, all with contacts rated for 2.0 amps @ 30 VDC (resistive) or 0.5 amps @ 30 VAC (resistive). The Alarm and Supervisory silk-screen labels reflect the factory default programming for the two programmable relays.
Notification Appliance Circuits Installation 2.4.1 Configuring NACs The Notification Appliance Circuits on the main circuit board are configured for Style Y or Style Z by properly orienting the NACKEY card in JP8 which is located at the top of the main circuit board near the NAC Terminal TB4. The default configuration is for Style Y (Class B).
UL Power-limited Wiring Requirements Installation 2.5 UL Power-limited Wiring Requirements Power-limited and nonpower-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” (6.35 mm) away from any nonpower-limited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through different knockouts and/or conduits.
Installation Optional Modules and Devices 2.6 Optional Modules and Devices WARNING! Disconnect all sources of power (AC and DC) before installing or removing any modules or wiring. MS-9600 Keypad/Display Removal Removal of the keypad/display is normally not necessary. If, however, it becomes necessary to replace the keypad/display, access the auxiliary trouble bus connectors at J16 and J17 or install the DACT-UD option module on J2, the Keypad/Display can be removed by inserting a Phillips screwdriver into each of the three holes located in the...
Optional Modules and Devices Installation 2.6.1 DACT-UD Installation WARNING! Disconnect all sources of power (AC and DC) before installing or removing any modules or wiring. The optional DACT-UD Digital Alarm Communicator/Transmitter transmits system status to UL listed Central Station receivers via the public switched telephone network. It is capable of reporting up to 99 software zones or up to 636 addressable points.
Page 34
Installation Optional Modules and Devices The following steps must be followed when installing the DACT module: 1. Remove all power (AC and DC) from FACP before proceeding with installation 2. Remove the Keypad/Display from the main circuit board as described in the beginning of this section 3.
Page 35
Optional Modules and Devices Installation 9. Refer to the Telephone Requirement and Warnings section of the DACT-UD Installation and Programming Manual Document #51889, before proceeding with this step. Connect the premises primary and secondary phone lines to the DACT as illustrated in Figure 2.14 and test the system for correct operation Secondary Lines Primary Lines Incoming Telco...
Installation Optional Modules and Devices 2.6.2 4XTMF Transmitter Module Installation The 4XTMF provides a supervised output for a local energy municipal box transmitter in addition to alarm and trouble reverse polarity. A jumper option allows the reverse polarity circuit to open with a system trouble condition if no alarm condition exists. A disable switch allows disabling of the transmitter output during testing to prevent accidental calling of the monitoring service.
Optional Modules and Devices Installation The following steps must be followed when installing the 4XTMF module: 1. Remove all power (AC and DC) from the FACP before installing 4XTMF 2. Cut jumper JP6 on the main circuit board to allow the control panel to supervise the 4XTMF module 3.
Installation Optional Modules and Devices 2.6.4 SLC-2 Expander Module The optional SLC-2 Expander Module provides a second SLC loop for the MS-9600 control panel. This allows connection of an additional 318 addressable devices, bringing the total to 636 addressable devices which can be connected to the FACP. Refer to the SLC Manual for information on connecting devices to the SLC.
Optional Modules and Devices Installation 2.6.5 Printer/PC A serial printer or a PC (personal computer) may be connected to TB7 Terminals 1 - 4 on the FACP. The printer can be used to provide a hard-copy printout of real-time events, history file and walktest data. An IBM compatible PC can be connected to provide local FACP programming capabilities using the PK-CD programming utility.
Installation Optional Modules and Devices 2.6.6 Digital Communicator and Annunciators 2.6.6.1 UDACT-F Digital Alarm Communicator/Transmitter The UDACT-F transmits system status to UL listed Central Station receivers via the public switched telephone network. It is capable of reporting up to 99 software zones or up to 636 addressable points.
Page 41
Optional Modules and Devices Installation Module Installation on BRKT-9600 The following modules can be installed inside the MS-9600 cabinet using the BRKT-9600 Universal Bracket: UDACT-F Digital Alarm Communicator/Transmitter - installs at standoff location (A) ACM-8RF Annunciator Control Module (Relay) - installs at standoff location Refer to the appropriate module manual for detailed information on module operation and wiring.
Installation Optional Modules and Devices 2.6.6.4 ACM and AFM Series Annunciators ACM and AFM Series Annunciators provide visual indications of FACP status in remote locations. Refer to the appropriate annunciator manual for information on installation, wiring and operation. Annunciator addressing is specific to the MS-9600 control panel. The following table describes the annunciator addresses and the corresponding addressable devices that will be annunciated at each annunciator address.
Programming Data Entry Programming Programming SECTION 3 3.1 Programming Data Entry Programming can be accomplished using the MS-9600 keypad or by connecting an optional standard computer keyboard. The keyboard can be connected to the PS-2 connector J7 on the control panel main circuit board. The information presented in this section refers to programming the MS-9600 via the onboard keypad.
Programming User Programming 3.2 User Programming The MS-9600 is completely field programmable and requires no special software skills. While programming the MS-9600, the fire protection capabilities of the control panel ! ! ! are enabled. Site-specific programming may be accomplished in three ways: •...
Initial Power-up Programming User Programming Levels There are two user programming levels: • User Master Program Level 1 is used for programming panel specific data relating to device types, zoning, messages, control panel functions, etc. • User Maintenance Program Level 2 is used by a qualified operator to access features such as Disable/Enable, View and Clear History, Walktest and System Time Change.
Page 46
Programming Programming and Passwords To access user Programming mode, press the Enter or Mode key. The LCD will display the following: 1=READ STATUS 2=PROGRAMMING 3=MANUAL DIAL MODE To enter the user Programming mode, press 2. The display will read as follows: PROGRAMMING ENTER PASSWORD *****...
Master Programming Level Programming 3.6 Master Programming Level When the Master Program Level password is entered, the control panel will enter user Programming mode. In this mode, the piezo sounder remains off, the trouble relay is activated and the system Trouble LED flashes until Programming mode is exited. The following display will appear: PROGRAMMING 1=AUTOPROGRAM...
Programming Master Programming Level 3.6.1 Autoprogram PROGRAMMING Pressing 1 while viewing Programming Screen #1, will select the Autoprogram option, 1=AUTOPROGRAM which prompts the control panel to poll all devices installed on one or both SLC loops. 2=POINT PROGRAM The primary purpose of autoprogramming is to allow the installer a fast and easy way to 3=ZONE SETUP bring the system on-line as quickly as possible.
Master Programming Level Programming 3.6.2 Point Program PROGRAMMING The Point Program option allows the programmer to add a new addressable device to an 1=AUTOPROGRAM SLC loop, delete an existing device from a loop or change the programming for an 2=POINT PROGRAM existing device.
Programming Master Programming Level When the last digit is keyed-in, the following screen will be displayed: ADD DETECTOR DETECTOR# IS ADDED The programmer can continue adding detectors by pressing the ESC or left arrow key which will return the display to the Add Detector Screen. 3.6.2.1.2 Delete Detector Pressing 2 in the Detector Screen will display the Delete Detector Screen which DETECTOR...
Page 51
Master Programming Level Programming When the last digit is keyed-in, if the selected address has not been added to programming, a screen showing information about a device with the highest address that is installed will be displayed. If no detectors have been installed on the loop, the following will be displayed: NO DETECTOR INSTALLED Edit Detector Screen #1...
Page 52
Programming Master Programming Level The following examples show the editing of a photoelectric smoke detector with address 017, located on the first SLC loop: EDIT DETECTOR 1D017 1=ENABLED 2=TYPE SMOKE(PHOTO) 3=VERIFICATION Edit Detector Screen #2 EDIT DETECTOR 1D017 1=WALKTEST 2=PAS 3=PRE-SIGNAL Edit Detector Screen #3 EDIT DETECTOR 1D017...
Page 53
Master Programming Level Programming Type To select the type of detector being programmed, press the 2 key while viewing the EDIT DETECTOR 1=ENABLED Edit Detector Screen #2. This will cause the control panel to display the following 2=TYPE Detector Type Screens: 3=VERIFICATION Edit Detector Screen #2 DETECTOR TYPE...
Page 54
Programming Master Programming Level To enable the PAS feature, press 2 while viewing the Edit Detector Screen #3 until the display reads PAS Yes. Each press of the 2 key will cause the display to toggle between PAS Yes and PAS No. Refer to "Positive Alarm Sequence" on page 120. See Page For example, if a detector with address 005 is to be configured for PAS operation: Select PAS Yes when editing the detector set to address 005...
Page 55
Master Programming Level Programming Zone Assignment A maximum of five zones can be programmed to each addressable detector. EDIT DETECTOR Pressing 1 while viewing Edit Detector Screen #4 displays the following screen: 1=ZONE ASSIGNMENT 00 ** ** ** ** ZONE ASSIGNMENT Edit Detector Screen #4 Z00 Z** Z** Z** Z** Zone Assignment Screen...
Page 56
Programming Master Programming Level Pressing 1 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN to see all the Adjective screens. Press the number corresponding to the adjective 3=CUSTOM ADJECTIVE that is to be used as a descriptor for the location of the detector currently being 4=CUSTOM NOUN...
Page 57
Master Programming Level Programming Pressing 2 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN to see all the Noun screens. Press the number corresponding to the noun that is to 3=CUSTOM ADJECTIVE be used as a descriptor for the location of the detector currently being programmed.
Page 58
Programming Master Programming Level Pressing 3 or 4 while viewing the Noun/Adjective Screen will display screens 1=STANDARD ADJECTIVE similar to the previous Adjective and Noun Screens. The new screens will list 2=STANDARD NOUN custom Adjectives and Nouns which have been programmed into the control panel 3=CUSTOM ADJECTIVE using the PK-CD programming kit.
Master Programming Level Programming As an example, the user could quickly enter ‘FLR_3_ROOM_305’ as follows: 1. The cursor is on the first letter of the Adjective field. Press the zero key twice to display FLR_3 2. With the cursor on the first letter of the Noun field, press the zero key twice to recall the display ROOM_304.
Programming Master Programming Level When the last digit is keyed-in, the following screen will be displayed: ADD MODULE 1=CONTROL 2=MONITOR Add Module Screen #2 Pressing 1 for Control Module or 2 for Monitor Module will cause the following screen to be displayed: ADD MODULE MODULE# IS ADDED...
Master Programming Level Programming 3.6.2.2.3 Edit Module Screen for Monitor Module The programmer can change a modules existing or factory default programming by pressing 3 in the Modules Screen. The following screen will be displayed: EDIT MODULE ENTER MODULE ADDRESS Edit Module Screen A flashing cursor will appear in the position of the first asterisk to the left.
Page 62
Programming Master Programming Level If the selected address corresponds to a control module, a screen displaying information about the control module with the selected address will be displayed as shown in "Edit Module Screen for Control Modules" on page 69. See Page If the selected address corresponds to a monitor module, a screen displaying information about the module with the selected address will be displayed as...
Page 63
Master Programming Level Programming Type Monitor EDIT MONITOR 1=ENABLED Using the PK-CD Upload/Download utility program, unique user-defined monitor 2=TYPE MONITOR types can be created and loaded into the FACP for later use. The FACP response to the activation of a user-defined type is the same as most previous standard types in Edit Monitor Screen #2 the list, thus allowing a variety of user-defined types and responses.
Page 64
Programming Master Programming Level Monitor module type selection will affect the function of the point as follows: Table 3.1 Monitor Types Monitor Type Action When Activated Pull-Station Fire Alarm User-Defined-1 same as previous (Pull-Station) Waterflow Fire Alarm Delayed User-Defined-2 same as previous (Waterflow) Monitor Fire Alarm User-Defined-3...
Page 65
Master Programming Level Programming Pre-signal EDIT MONITOR 1=PRE-SIGNAL To enable the Pre-signal feature, press 1 while viewing Edit Monitor Screen #3 until 2=PAS the display reads Pre-signal Yes. Each press of the 1 key will cause the display to toggle between Pre-signal Yes and Pre-signal No. Refer to "Presignal" on page 119 Edit Monitor Screen #3 for additional information.
Page 66
Programming Master Programming Level Pressing 1 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN 3=CUSTOM ADJECTIVE to see all the Adjective screens. Press the number corresponding to the adjective 4=CUSTOM NOUN that is to be used as a descriptor for the location of the monitor module currently Noun/Adjective Screen...
Page 67
Master Programming Level Programming Pressing 2 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN 3=CUSTOM ADJECTIVE to see all the Noun screens. Press the number corresponding to the noun that is to 4=CUSTOM NOUN be used as a descriptor for the location of the monitor module currently being Noun/Adjective Screen...
Page 68
Programming Master Programming Level Description EDIT MONITOR 1=NOUN/ADJECTIVE The Description selection allows the programmer to enter additional information 2=DESCRIPTION about the monitor module currently being programmed. This information will be ***************** displayed as part of the device label on the LCD display. Pressing 2 while viewing Edit Monitor Screen #5 Edit Monitor Screen #5 will cause the following screen to be displayed: DESCRIPTION...
Master Programming Level Programming As an example, the user could quickly enter ‘FLR_3_ROOM 305’ as follows: 1. The cursor is on the first letter of the Adjective field. Press the zero key twice to display FLR_3 2. With the cursor on the first letter of the Noun field, press the zero key twice to recall the display ROOM_304.
Page 70
Programming Master Programming Level To change the programming for the displayed module, press the keyboard down arrow key to view the following Edit Control screens: EDIT CONTROL 1=ENABLED 2=TYPE CONTROL 3=SILENCEABLE Edit Control Screen #2 EDIT CONTROL 1=WALKTEST 2=ZONE ASSIGNMENT 00 ** ** ** ** Edit Control Screen #3 EDIT CONTROL...
Page 71
Master Programming Level Programming Type EDIT CONTROL 1=ENABLED To select the type of control module being programmed, press the 2 key while 2=TYPE viewing the Edit Control Screen #2. This will cause the control panel to display the 3=SILENCEABLE following Control Type Screens: Edit Control Screen #2 CONTROL TYPE 1=FUTURE USE...
Page 72
Programming Master Programming Level Silenceable EDIT CONTROL 1=ENABLED The Silenceable selection allows the programmer to select whether output devices 2=TYPE connected to the control module can be silenced, either by pressing the Alarm 3=SILENCEABLE Silence key or by enabling Autosilence. Pressing the 3 key while viewing Edit Edit Control Screen #2 Control Screen #2 will enable the Silenceable feature causing the display to read Silenceable Yes.
Page 73
Master Programming Level Programming Pressing 1 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN 3=CUSTOM ADJECTIVE to see all the Adjective screens. Press the number corresponding to the adjective 4=CUSTOM NOUN that is to be used as a descriptor for the location of the control module currently Noun/Adjective Screen...
Page 74
Programming Master Programming Level Pressing 2 while viewing the Noun/Adjective Screen will cause the following 1=STANDARD ADJECTIVE screen(s) to be displayed. Note that the keyboard down arrow key must be pressed 2=STANDARD NOUN 3=CUSTOM ADJECTIVE to see all the Noun screens. Press the number corresponding to the noun that is to 4=CUSTOM NOUN be used as a descriptor for the location of the control module currently being Noun/Adjective Screen...
Page 75
Master Programming Level Programming Description EDIT CONTROL 1=ADJECTIVE/NOUN The Description selection allows the programmer to enter additional information 2=DESCRIPTION about the control module currently being programmed. This information will be displayed as part of the device label on the display. Pressing 2 while viewing Edit Edit Control Screen #4 Control Screen #4 will cause the following screen to be displayed: DESCRIPTION...
Programming Master Programming Level 3.6.3 Zone Setup PROGRAMMING 1=AUTOPROGRAM Pressing 3 while viewing Programming Screen #1 will access the Zone Setup screens as 2=POINT PROGRAM illustrated below: 3=ZONE SETUP Programming Screen #2 ZONE SETUP 1=ENABLE 2=DISABLE 3=ZONE 97 98 99 Zone Setup Screen #1 ZONE SETUP 1=ZONES INSTALLED...
Master Programming Level Programming 3.6.3.2 Disable ZONE SETUP 1=ENABLE Pressing 2 for Disable, while viewing Zone Setup Screen #1, will display the 2=DISABLE following screen: 3=ZONE 97 98 99 Zone Setup Screen #1 ZONE TO DISABLE Disable Screen This screen allows the programmer to disable zones, one at a time. A flashing cursor appears next to the Z, prompting the programmer to enter a two digit zone number (01 - 99).
Programming Master Programming Level 3.6.3.4 Zones Installed ZONE SETUP Pressing 1 for Zones Installed, while viewing Zone Setup Screen #2, will display a 1=ZONES INSTALLED 2=ZONES ENABLED screen similar to the following: 3=ZONES DISABLED Zone Setup Screen #2 ZONES INSTALLED 00 01 02 03 04 05 Zones Installed Screen This display will show all of the zones that have been programmed into the control...
Master Programming Level Programming 3.6.3.7 Zone Type ZONE SETUP 1=ZONE TYPES Zone Types must be programmed only if a DACT, programmed for zone reporting, is installed on the control panel. Pressing 1 for Zone Types, while viewing Zone Setup Screen #3, will display a screen similar to the following: Zone Setup Screen #3 ZONE TYPE PROG 1=Z00...
Programming Master Programming Level 3.6.4 Loop Setup PROGRAMMING 1=LOOP SETUP Loop Setup allows the programmer to configure the SLC Loop(s) for NFPA Style 4, 6 2=SYSTEM SETUP or 7 wiring and to select the protocol for each loop. Pressing 1 while viewing 3=VERIFY LOOPS Programming Screen #2 will cause the following screen to be displayed: Programming Screen #2...
Master Programming Level Programming 3.6.5 System Setup System Setup allows the programmer to configure the following control panel features: • Trouble Reminder: This feature, when enabled, provides an audible reminder that an alarm or trouble still exists on the FACP after the control panel has been silenced.
Programming Master Programming Level 3.6.5.1 Trouble Reminder The Trouble Reminder features causes the control panel piezo to sound a reminder ‘beep’ for alarms and troubles, after the panel has been silenced. Refer to "System Setup" on page 81, for a detailed description of this feature. Pressing 1 while viewing System Setup Screen #1 will cause the display to toggle to Trouble Rem See Page On, which enables this feature.
Master Programming Level Programming These screens allow the programmer to enter a two line custom banner. A flashing cursor will appear in the bottom left corner of each display. A maximum of 20 characters (including spaces) can be entered into each screen for a total of two lines with 40 characters.
Programming Master Programming Level 3.6.5.3.2 Date To change the date, press 2 while viewing the Time-Date Screen. The following screen will be displayed: ENTER DATE MONTH DAY YEAR 04-07-2001 Date Screen A flashing cursor is located toward the top left of the display. Below the cursor is the current date.
Master Programming Level Programming Pressing 3 while viewing Daylight Savings Screen #1 will display two sub-screens which allow the programmer to select the week of the month that daylight savings time will begin. In the first sub-screen, pressing 1 will select the first week, 2 will select the second week and 3 will select the third week, while in the second sub- screen, pressing 1 will select the fourth week and 2 will select the last week of the selected month.
Programming Master Programming Level 3.6.5.4.2 Pre-signal Delay The factory default setting for Pre-signal delay is 000 for no delay. To select a Pre- signal delay of 001 to 180 seconds for all devices programmed for Pre-signal, press 2 while viewing Timer Screen #1. The following screen will be displayed: PRESIGNAL DELAY RANGE 0-180 SECONDS Pre-signal Delay Screen...
Master Programming Level Programming 3.6.5.4.4 AC Loss Delay TIMER The reporting of a loss of AC power to a central station can be delayed by 1=AC LOSS DELAY programming the length of the desired delay. Press 1 while viewing Timer Screen #2 to display the following: Timer Screen #2 AC LOSS DELAY...
Master Programming Level Programming 3.6.5.5.2 Type NAC # The main circuit board NAC type can be programmed by pressing 2 while viewing 1=ENABLED 2=TYPE NAC Screen #1. The following screens will be displayed: 3=SILENCEABLE NAC Screen #1 NAC TYPE 1=BELL 2=HORN 3=STROBE Type Screen #1...
Programming Master Programming Level 3.6.5.5.4 Auto Silence NAC # The Auto Silence feature, when enabled, automatically silences all main circuit 1=AUTO SILENCE 2=CODING board silenceable notification appliances after a programmed length of time. To TEMPORAL enable this feature and program the time delay before Auto Silence activation, press NAC Screen #2 1 while viewing NAC Screen #2.
Page 91
Master Programming Level Programming The programmer can select the notification appliance output by pressing the number corresponding to the desired output. The coding selections are: • Steady - a continuous output with no coding • March Time - 120 ppm (pulse-per-minute) output •...
Programming Master Programming Level 3.6.5.5.6 Zone NAC # A maximum of five zones can be programmed to each main circuit board NAC. 1=ZONE 00 00 00 00 00 Pressing 1 while viewing NAC Screen #3 displays the following screen: 2=SIL INHIBITED NO NAC Screen #3 ZONE ASSIGNMENT Z00 Z** Z** Z** Z**...
Master Programming Level Programming 3.6.5.6 Relays SYSTEM SETUP 1=TIMERS Pressing 3 while viewing System Setup Screen #2 will allow the programmer to 2=NAC configure two of the three main circuit board Form-C relays. The following screen 3=RELAYS will be displayed: System Setup Screen #2 RELAYS 1=RELAY 1...
Programming Master Programming Level 3.6.5.7 Canadian Option SYSTEM SETUP Pressing 1 while viewing System Setup Screen #3 will allow the programmer to 1=CANADIAN OPT. OFF 2=WATERFLOW SIL. NO configure the system to automatically monitor addressable ionization smoke detector sensitivity using Canadian specifications. The display will change to System Setup Screen #3 Canadian Opt.
Master Programming Level Programming 3.6.7 History PROGRAMMING The History option allows an authorized user to view or erase events which have 1=HISTORY occurred in the control panel. Pressing 1 while viewing Programming Screen #3 will 2=WALKTEST display the History options as shown in the following display: 3=OPTION MODULES Programming Screen #3 HISTORY...
Programming Master Programming Level 3.6.8 Walktest PROGRAMMING Walktest allows an individual to test the fire alarm system without the necessity to reset 1=HISTORY the control panel after each device activation. Pressing 2 while viewing the 2=WALKTEST Programming Screen #3 will cause the following Walktest options to be displayed: 3=OPTION MODULES Programming Screen #3 WALKTEST...
Master Programming Level Programming 3.6.9 Option Modules PROGRAMMING Options available for the MS-9600 include ACM Series, Graphic and LCD 1=HISTORY annunciators, UDACT-F Digital Alarm Communicator/Transmitter, printer connection 2=WALKTEST for acquiring hardcopy printouts of panel data and PC (Personal Computer) connection 3=OPTION MODULES for uploading and downloading panel data.
Programming Master Programming Level If an ACS annunciator is installed, press 1 while viewing Annunciator Screen #2 to select addresses for the ACS annunciators. The following screen will be displayed: ANNUNCIATORS 1=ADDRESS 1 2=ADDRESS 2 3=ADDRESS 3 ACS Installed Screen Pressing the down arrow key will allow the programmer to view additional screens displaying Addresses 1 -31.
Master Programming Level Programming Pressing the number key corresponding to the desired baud rate (2 for 4800 Baud for example) will program the control panel for the selected baud rate and return the display to the Option Module Screen which will indicate Printer/PC PR4800 for a supervised printer installed at 4800 baud rate.
Programming Master Programming Level 3.6.11 Clear Program PROGRAMMING Pressing 2 while viewing Programming Screen #4, will select the Clear Program 1=PASSWORD CHANGE option. This will cause the LCD to display the following screens: 2=CLEAR PROGRAM 3=PROGRAM CHECK CLEAR PROGRAM Programming Screen #4 1=WHOLE SYSTEM 2=ALL LOOPS 3=LOOP1...
Master Programming Level Programming 3.6.12 Program Check PROGRAMMING The Program Check feature allows the programmer to view the zones which have been 1=PASSWORD CHANGE programmed to the Notification Appliance Circuits on the control panel but have not 2=CLEAR PROGRAM been programmed to Initiating Devices as well as other circuits with no input or output 3=PROGRAM CHECK correlations.
Page 102
Programming Master Programming Level Pressing 2 while viewing the Program Check screen will display a screen similar to the following: ZONES NO INPUT 05 07 09 10 11 1M001 The Zone No Input screen allows the programmer to view the zones which have not been programmed to at least one input device (not including general alarm Zone 00).
Maintenance Programming Level Programming 3.7 Maintenance Programming Level To access Maintenance Programming mode, press the Enter key. The LCD will display the following: 1=READ STATUS 2=PROGRAMMING To enter the Maintenance Programming mode, press 2. The display will read as follows: PROGRAMMING ENTER PASSWORD When the Maintenance level password (default 11111) is entered, the following screen...
Programming Maintenance Programming Level 3.7.1 Disable Point PROGRAMMING Pressing 1 for Point Program, while viewing Maintenance Screen #1 will cause the 1=POINT PROGRAM following screens to be displayed: 2=HISTORY 3=PROGRAM CHECK POINT PROGRAM Maintenance Screen #1 1=LOOP 1 2=LOOP 2 Loop Select Screen Select the Loop, containing the device to be disabled, by pressing 1 for Loop 1 or 2 for Loop 2.
Maintenance Programming Level Programming 3.7.2 History PROGRAMMING Pressing 2 while viewing Maintenance Screen #1 will cause the following screen to be 1=POINT PROGRAM displayed: 2=HISTORY 3=PROGRAM CHECK HISTORY Maintenance Screen #1 1=VIEW EVENTS 2=ERASE HISTORY History Screen The History feature allows the operator to view control panel events which have been stored in a history file in memory and erase the contents of the history file Pressing 1 while viewing the History screen will cause the following screen to be displayed:...
Programming Maintenance Programming Level 3.7.3 Program Check PROGRAMMING Pressing 3 while viewing Maintenance Screen #1 will cause the following screen to be 1=POINT PROGRAM displayed: 2=HISTORY 3=PROGRAM CHECK PROGRAM CHECK Maintenance Screen #1 1=NACS NO INPUT 2=ZONES NO INPUT 3=ZONE NO OUTPUT Program Check Screen The Program Check feature allows the programmer to view the zones which have been programmed to the Notification Appliance Circuits on the control panel but have not...
Maintenance Programming Level Programming Pressing 3 while viewing Program Check screen will cause a screen similar to the following to be displayed: ZONES NO OUTPUT 05 07 09 10 11 1D001 The Zone No Output feature allows the programmer to view the zones which have not been programmed to at least one output device (not including general alarm Zone 00).
Page 108
Programming Maintenance Programming Level Pressing 1 while viewing the System Screen will cause the following screen to be displayed: TIME AND DATE 1=TIME 01:00 AM 2=DATE 01-01-2001 12HR Time and Date Screen To change the time, press 1 to display the following screen: ENTER TIME 01:00 AM 1=AM...
Maintenance Programming Level Programming 3.7.6 Zone Setup PROGRAMMING Pressing 3 while viewing Maintenance Screen #2 will display the following screen: 1=WALKTEST 2=SYSTEM 3=ZONE SETUP Maintenance Screen #2 ZONE SETUP 1=ENABLE 2=DISABLE 3=ZONE 97 98 99 Zone Setup Screen Pressing 1 while viewing Zone Setup screen will display the following screen: ZONE TO ENABLE Enable Screen A flashing cursor appears to the right of the Z.
Page 110
Programming Maintenance Programming Level Pressing 3 while viewing Zone Setup screen will display the following screen: SPEC PURPOSE ZONE 1=PAS 97 2=PRE-SIGNAL 98 3=FUTURE 99 Disable Screen Zones 97, 98 and 99 can be programmed for normal zone operation or for special purpose applications.
Panel Control Buttons Operating Instructions Operating Instructions SECTION 4 4.1 Panel Control Buttons 4.1.1 Acknowledge/Step The first press of the Acknowledge/Step key silences the piezo sounder, changes flashing LEDs to steady and also changes the status field on the LCD display from capital letters to small letters.
Operating Instructions LED Indicators 4.2 LED Indicators The nine LED indicators, which are located on the front panel, operate as follows: AC Power This is a green LED which illuminates if AC power is applied to the FACP. A loss of AC power will turn off this LED Fire Alarm This red LED flashes when one or more alarms occur.
Normal Operation Operating Instructions 4.3 Normal Operation With no alarms or troubles in the system, the display message is System All Normal along with the current time and date as shown below. To set the time and date, refer to the appropriate section in this manual.
Page 114
Operating Instructions Trouble Operation Addressable Smoke Detectors, Monitor Modules and Control Modules For addressable devices connected to the SLC loop, the following is a typical message that could appear on the LCD display for a device trouble: TROUBL SMOKE (PHOTO) <ADJ>...
Alarm Operation Operating Instructions Pressing the Acknowledge/Step or Alarm Silence key will cause the pulsing piezo to silence and the system Trouble LED to change from flashing to on steady. This block acknowledgment occurs regardless of the number of troubles, alarms and supervisory events active in the system.
Operating Instructions Supervisory Operation • Second line in display: <ADJ>; refers to the user programmed adjective descriptor from library list resident in the control panel or custom entry via PC. <NOUN>; refers to the user programmed noun descriptor from library list resident in the control panel or custom entry via PC.
Process Monitor Operation Operating Instructions 4.7 Process Monitor Operation Process Monitor operation will initiate the following events: • The piezo sounder pulses ¼ second On and ¼ second Off • The LCD displays a process monitor message along with the device name, type, address, adjective/noun, associated zones and time/date •...
Operating Instructions Disable/Enable Operation 4.11 Disable/Enable Operation Input points which are disabled do not cause an alarm or any zone activation. Disabled output points are held in the off state. All disabled points are treated as if they were in trouble, with the exception being the status label that will be displayed is DISABL.
Synchronized NAC Operation Operating Instructions 4.16 Synchronized NAC Operation Synchronization is a panel feature that controls the activation of notification appliances in such a way that all devices will turn on and off at exactly the same time. This is particularly critical when activating strobes which must be synchronized to avoid random activation and a potential hazard or confusion.
Operating Instructions Positive Alarm Sequence 4.19 Positive Alarm Sequence PAS (Positive Alarm Sequence) option will program an initiating device to delay panel activation (including alarm relay and communicator) for a period of 15 seconds. Zone 97, however, will activate immediately and may be used to connect a signaling device to indicate PAS activation.
Special System Timers Operating Instructions 4.20 Special System Timers 4.20.1 Silence Inhibit Timer This option, if selected, prevents the Alarm Silence and Reset keys from functioning for 60 seconds following an alarm. A second alarm during this 60 second period will not cause the timer to restart with a new 60 seconds.
Operating Instructions Walktest 4.20.5 Alarm Verification If alarm verification is selected, an addressable smoke detector's alarm is ignored for a retard time of 13 seconds and the detector's alarm condition is automatically reset. There will be no alarm indication at the FACP during the Retard period. A confirmation period of 60 seconds follows, during which a subsequent alarm from the same detector will cause the panel to immediately activate the appropriate outputs and indicate the alarm condition at the FACP.
Read Status Operating Instructions 4.22 Read Status Read Status functions do not require a password. The control panel will continue to provide fire protection while in Read Status mode. This mode can be entered while the control panel is in alarm or trouble. If a new alarm or trouble occurs during these functions, the Read Status is exited to prevent confusion.
Operating Instructions Read Status 4.22.1 System Point READ STATUS Pressing 1 while viewing Read Status Screen #1 will cause the following screen to be 1=SYSTEM POINT displayed: 2=ZONES 3=POWER Read Status Screen #1 READ SYSTEM POINT SELECT LOOP 1=LOOP 1 2=LOOP 2 The operator selects the loop containing the device to be read by pressing 1 for Loop 1 or 2 for Loop 2.
Read Status Operating Instructions Pressing the down arrow key, while viewing the screen shown above, will allow the operator to view additional programming information about the selected device, such • Enable/Disable Status • Device Type • Alarm Verification On/Off • Walktest Yes/No •...
Page 126
Operating Instructions Read Status 4.22.3 Power Pressing 3 while viewing Read Status Screen #1 will display the following screens: POWER BATTERY 27.21V 24 V RST 25.31V Zones Screen #1 POWER CHARGER 28.36V NAC 1 -2.39V NAC 2 -2.39V Zones Screen #2 POWER NAC 3 -2.39V...
Read Status Operating Instructions 4.22.4 Trouble Reminder READ STATUS Pressing 1 while viewing Read Status Screen #2 will display the following screen: 1=TROUBLE REMINDER 2=TIMERS 3=NACS Read Status Screen #2 TROUBLE REMINDER TROUBLE REM The screen indicates whether the Trouble Reminder feature is On or Off. 4.22.5 Timers Pressing 2 while viewing Read Status Screen #2 will cause the following Timer screens to be displayed:...
Operating Instructions Read Status 4.22.6 NAC Pressing 3 while viewing Read Status Screen #2 will display the following screen: 1=NAC 1 3=NAC 3 2=NAC 2 4=NAC 4 Note that 3=NAC 3 and 4=NAC 4 will only be displayed if the NACKEY NAC option card is installed, in JP8 of the main circuit board, for Class B operation.
Read Status Operating Instructions 4.22.8 Program Check Pressing 2 while viewing Read Status Screen #3 will cause a screen similar to the following to be displayed: PROGRAM CHECK 1=NACS NO INPUT 2=ZONES NO INPUT 3=ZONES NO OUTPUT Pressing 1 while viewing the Program Check screen will display a screen which will indicate if any input zones have not been programmed to one of the Notification Appliance Circuits.
Operating Instructions Read Status 4.22.10 Annunciators READ STATUS Pressing 1 while viewing Read Status Screen #4 will display the following screens: 1=ANNUNCIATORS 2=PHONE LINES 3=CENTRAL STATION ANNUNCIATORS Read Status Screen #4 TERM ENABLED ACS ENABLED UDACT ENABLED Annunciator Screen #1 ANNUNCIATORS 1=ACS ADDRESSES Annunciator Screen #2...
Read Status Operating Instructions 4.22.12 Central Station READ STATUS Pressing 3 while viewing Read Status Screen #4 will display the following screens: 1=ANNUNCIATORS 2=PHONE LINE 3=CENTRAL STATION Read Status Screen #4 CENTRAL STATION REPORTING ENABLED REPORT BOTH CALL LIMIT Central Station Screen #1 CENTRAL STATION 1=PRIMARY 2=SECONDARY...
Operating Instructions Read Status 4.22.13 Service Terminal READ STATUS Pressing 1 while viewing Read Status Screen #5 will display the following screens: 1=SERVICE TERMINAL 2=PRINTER/PC 3=PRINT SERVICE TERMINAL Read Status Screen #5 PANEL ID 2=TERMINAL 1 3=TERMINAL 2 Service Terminal Screen #1 SERVICE TERMINAL RING COUNT Service Terminal Screen #2...
Read Status Operating Instructions 4.22.15 Print READ STATUS To print program data or control panel status, press 3 while viewing Read Status Screen 1=SERVICE TERMINAL #5. The following screens will be displayed: 2=PRINTER/PC 3=PRINT Read Status Screen #5 PRINT 1=HISTORY 2=WALKTEST LOG 3=DETECTOR DATA Print Screen #1...
Page 134
Operating Instructions Read Status Drift Compensation Drift compensation uses software algorithms that identify and compensate for long- term changes in the data readings from each addressable smoke detector. These long- term changes in detector data readings are typically caused by dirt and dust accumulation inside the smoke chamber.
Read Status Operating Instructions 4.22.16 Time-Date READ STATUS The operator can view the daylight savings time and the month and week when daylight 1=TIME-DATE savings time will begin and end. Pressing 1 while viewing Read Status Screen #6 will display the following screens: Read Status Screen #6 DAYLIGHT SAVINGS ENABLED...
Power Supply Calculations Overview Power Supply Calculations SECTION 5 5.1 Overview This section contains instructions and tables for calculating power supply currents in alarm and standby conditions. This is a four-step process, consisting of the following: 1. Calculating the total amount of AC branch circuit current required to operate the system 2.
Calculating the System Current Draw Power Supply Calculations 5.3 Calculating the System Current Draw 5.3.1 Overview The control panel must be able to power all internal and external devices continuously during the non-fire alarm condition. To calculate the non-fire alarm load on the system power supply when primary power is applied, use Calculation Column 1 in Table 5.3 on page 138.
Page 138
Power Supply Calculations Calculating the System Current Draw Table 5.3 contains columns for calculating current draws. For each column, calculate the current and enter the total (in amperes) in the bottom row. When finished, copy the totals from Calculation Column 2 and Calculation Column 3 to Table 5.4 on page 139. Table 5.3 System Current Draw Calculations Calculation Column 1 Calculation Column 2...
Calculating the Battery Size Power Supply Calculations 5.4 Calculating the Battery Size Use Table 5.4 to calculate the total Standby and Alarm load in ampere hours (AH). This total load determines the battery size (in AH), required to support the control panel under the loss of AC power.
Software Zones Correlations Software Zones APPENDIX A A.1 Correlations Setup and configuration of an addressable system is different than a conventional system. In a conventional system, assignment of input devices (smoke detectors, pull stations, heat detectors, etc.) to zones is accomplished through wiring. The wiring is direct from clearly marked panel terminals to any device assigned to a particular zone.
Page 141
Correlations Software Zones Correlation of Input and Output Zones Input Devices Zones Output Devices SD350 CMF-300 SD350 CMF-300 ZONE MMF-300 CMF-300 MMF-302 CMF-300 CMF-300 MMF-302 CMF-300 CP350 ZONE CMF-300 CP300 SD350 CMF-300 SD350 ZONE SD350 CMF-300 MMF-302 The zone correlations which are shown graphically above are also presented in Table A.1 on page 142 and Table A.2 on page 143.
Page 142
Software Zones Correlations Table A.1 Detector Programming Sheet Example DETECTOR ZONE ASSIGNMENT Address Device Zone ADJ/NOUN Address Device Zone ADJ/NOUN Type Number Type Number SD350 FIRST HALL SD350 ELEV. LOBBY CP350 2ND FLOOR CP350 ROOM 210 SD350 3RD FLOOR SD350 MEZZANINE SD350 MECH.
Page 143
Correlations Software Zones Table A.2 Module Programming Sheet Example MONITOR/CONTROL MODULE ZONE ASSIGNMENT Address Device Zone ADJ/ Address Device Zone ADJ/NOUN Type Number NOUN Type Number MMF-300 MMF-302 1, 2 MMF-302 1, 2 MMF-302 CMF-300 CMF-300 CMF-300 CMF-300 CMF-300 1, 2, 3 CMF-300 CMF-300 CMF-300...
Page 144
Software Zones Correlations Table A.3 Blank Detector Programming Sheet - 1 of 2 DETECTOR ZONE ASSIGNMENT Address Device Zone ADJ/ Address Device Zone ADJ/NOUN Type Number NOUN Type Number MS-9600 PN 51335:E1 2/14/08...
Page 145
Correlations Software Zones Table A.4 Blank Detector Programming Sheet - 2 of 2 DETECTOR ZONE ASSIGNMENT Address Device Zone ADJ/ Address Device Zone ADJ/NOUN Type Number NOUN Type Number MS-9600 PN 51335:E1 2/14/08...
Page 146
Software Zones Correlations Table A.5 Blank Module Programming Sheet - 1 of 2 MONITOR/CONTROL MODULE ZONE ASSIGNMENT Address Device Zone ADJ/ Address Device Zone ADJ/NOUN Type Number NOUN Type Number MS-9600 PN 51335:E1 2/14/08...
Page 147
Correlations Software Zones Table A.6 Blank Module Programming Sheet - 2 of 2 MONITOR/CONTROL MODULE ZONE ASSIGNMENT Address Device Zone ADJ/ Address Device Zone ADJ/NOUN Type Number NOUN Type Number MS-9600 PN 51335:E1 2/14/08...
Default Programming Correlations Default Programming APPENDIX B The following table provides a list of the programming options and their factory default settings. Program Option Factory Default Program Option Factory Default Detector Programming Not Installed Daylight Savings Detector Type Smoke-Photo Month Start Daylight Savings April Detector Verification Week Start Daylight Savings...
Correlations NFPA Standard-Specific Requirements NFPA Standard-Specific Requirements APPENDIX C The Fire•Lite MS-9600 has been designed for use in commercial, industrial and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this Appendix. The minimum system components required for compliance with the appropriate NFPA standard are listed below: MS-9600 Control Panel...
Page 150
NFPA Standard-Specific Requirements Correlations NFPA Signaling Systems for Central Station Service (Protected Premises Unit)/ Remote Station The following figure illustrates an example of Central Station/Remote Station Reporting using a 411UDAC. The relay contacts from the MS-9600 may be used to trip any dialer UL listed for Central Station/Remote Station Services.
Page 151
Correlations NFPA Standard-Specific Requirements The following figure illustrates an example of Central Station/Remote Station Reporting using a UDACT-F (Universal Digital Alarm Communicator/Transmitter). The UDACT-F transmits system status to UL listed Central Station receivers via the public switched telephone network. It may be mounted inside the MS-9600 cabinet using the BRKT-9600 mounting bracket or remotely in a UBS-1F or ABS-8RF enclosure.
Page 152
NFPA Standard-Specific Requirements Correlations The following figure illustrates an example of Central Station/Remote Station Reporting using a 411UD. The relay contacts from the MS-9600 may be used to trip any dialer UL listed for Central Station/Remote Station Reporting Services. Note: The Monitor Module input, which is being used to monitor the 411UD Relay #2 Output (programmed for DACT Trouble), must be programmed as ‘Trouble’...
Page 153
Correlations NFPA Standard-Specific Requirements NFPA 72 Auxiliary Fire Alarm System All connections are power-limited and supervised. This application is not suitable for separate transmission of sprinkler supervisory or trouble conditions. Notes: 1. 3 ohms maximum loop resistance allowed for wiring from control panel to Municipal Box. 2.
Page 154
NFPA Standard-Specific Requirements Correlations NFPA 72 Remote Station Protective Signaling System Notes: 1. Cut Jumper JP6 on the MS-9600 main circuit board to supervise placement of the 4XTMF module. 2. Refer to "4XTMF Transmitter Module Installation" on page 36 for detailed information. Fire•Lite RS82 Remote Station Receiver UL listed.
Page 155
Correlations NFPA Standard-Specific Requirements NFPA 72 Proprietary Protective Signaling Systems MS-9600 Addressable Fire Control Panel MS-9600 Main Board Form-C Alarm contact programmed to activate on General Alarm. Form-C Trouble contact which will automatically activate on any Trouble condition. Form-C relay contact programmed to activate on Supervisory condition.
Wire Requirements Correlations Wire Requirements APPENDIX D T-tapping of the SLC loop wiring is allowed for 2-wire (Style 4) configurations. The total resistance of any branch cannot exceed 40 ohms. The total wire length of all branches cannot exceed 10,000 feet (3,000 m). Connecting external system accessories to the MS-9600 main circuits must be carefully considered to ensure proper operation.
Page 157
Index Numerics AFM-32AF Annunciator 22 CHG-120F 300 Series addressable devices 20 Alarm 115 see also battery charger 22 4XTMF 153, 154 Alarm Silence 16, 111 see also remote battery charger 4XTMF module alarm verification 12, 53, 118, 122 coil resistance 36 annunciator 22 CHG-75 current 36...
Page 158
Index see also detector data and sensi- for PC/Printer connection 15 tivity 118 see also Printer/PC interface 12 lamp test 16 values 12 EIA-485 LCD display 12, 16 Data Entry for ACS annunciators 15 LCD-80F annunciator 13, 23 via computer keyboard 43 for LCD-80F 15 LDM Series annunciator 23 via keypad 43...
Page 159
Index type action 64 power supply calculations 136 Type list 63 see also NAC 12, 28 power-limited type selection 64 Noun relay connections 28 Mounting monitor module 67 Power-up cabinet 24 multiple entries 58 first time 45 main circuit board 24 Noun list 57 Pre-signal 13, 54, 77 municipal box transmitter...
Page 160
Index printer/PC 132 Trouble 113 program check 129 Style 17 trouble display 114 relay 128 voltage 14 trouble relay 12 system point 124 wiring length 14 Trouble Reminder 81, 121, 127 Time-Date 135 SLC Loop Protocol 80 trouble responses 114 timers 127 SLC loop selection 49 two stage operation 91...
Page 161
Index wiring modules see also Style B or Style D 19 wiring Style 12 Z00 55, 65 PAS zone 54 Z98 54 Zone 97 77 Zone 98 77 Zone Assignment 55, 65, 92 control module 72 Zone Setup 76 Maintenance Level 109 zone type 79 list 79 Zone Z97 54...
Page 163
This warranty is void if the product is altered or repaired by anyone other than Honeywell International Inc. or as expressly authorized by Honeywell International Inc.
Page 164
World Headquarters 1 Firelite Place Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.firelite.com...
