3 . 1 3 . 5 W P S
3 . 1 3 . 5 W P S
WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection
between wireless station and wireless access point (vigor router) with the encryption of
WPA and WPA2.
Note: Such function is available for the wireless station with WPS supported.
It is the simplest way to build connection between wireless network clients and vigor router.
Users do not need to select any encryption mode and type any long encryption passphrase to
setup a wireless client every time. He/she only needs to press a button on wireless client, and
WPS will connect for client and router automatically.
There are two methods to do network connection through WPS between AP and Stations:
pressing the Start PBC button or using PIN Code.
On the side of Vigor 2930 series which served as an AP, press Factory Reset button
once on the front panel of the router or click Start PBC on web configuration interface.
On the side of a station with network card installed, press Start PBC button of network
card.
If you want to use PIN code, you have to know the PIN code specified in wireless
client. Then provide the PIN code of the wireless client you wish to connect to the
Delete the selected MAC address in the list.
Edit the selected MAC address in the list.
Give up the access control set up.
Click it to save the access control list.
Clean all entries in the MAC address list.
210
Vigor2930 Series User's Guide
