Advanced Backup
Profile Name
ERD Mode
Detail Information
3 . 9 . 1 0 C o n n e c t i o
3 . 9 . 1 0 C o n n e c t i o
You can find the summary table of all VPN connections. You may disconnect any VPN
connection by clicking Drop button. You may also aggressively Dial-out by using Dial-out
Tool and clicking Dial button. After adding a new VPN TRUNK profile, it will be listed in
Backup/Load Balance Mode drop-down list for you to choose for dialing.
General Mode
List the backup profile name.
ERD means "Environment Recovers Detection".
Normal – choose this mode to make all dial-out VPN
TRUNK backup profiles being activated alternatively.
Recover Timer – choose this mode to detect VPN connection
periodically and type the value for it (the unit is second). If
VPN server for Member 1 has completed the network
connection, current VPN Tunnel backup connection will be
off.
Resume – when VPN connection breaks down or disconnects,
Member 1 will be the top priority for the system to do VPN
connection.
This field will display detailed information for Environment
Recovers Detection.
n M a n a g e m e n t
n M a n a g e m e n t
This filed displays the profile configured in LAN-to-LAN
(with Index number and VPN Server IP address). The VPN
connection built by General Mode does not support VPN
156
Vigor2930 Series User's Guide
