WPA
WEP
3 . 1 3 . 4 A c c e s s C o
3 . 1 3 . 4 A c c e s s C o
For additional security of wireless access, the Access Control facility allows you to restrict
the network access right by controlling the wireless LAN MAC address of client. Only the
valid MAC address that has been configured can access the wireless LAN interface. By
clicking the Access Control, a new web page will appear, as depicted below, so that you
could edit the clients' MAC addresses to control their access rights.
WPA2/802.1x Only- Accepts only WPA2 clients and the
encryption key is obtained dynamically from RADIUS server
with 802.1X protocol.
Mixed (WPA+WPA2/802.1x only) - Accepts WPA and WPA2
clients simultaneously and the encryption key is obtained
dynamically from RADIUS server with 802.1X protocol.
WPA/PSK-Accepts only WPA clients and the encryption key
should be entered in PSK.
WPA2/PSK-Accepts only WPA2 clients and the encryption key
should be entered in PSK.
Mixed (WPA+ WPA2)/PSK - Accepts WPA and WPA2
clients simultaneously and the encryption key should be entered
in PSK. Default Pre-Shared Key (PSK) is provided and stated
on the label pasted on the bottom of the router. For the wireless
client who wants to access into Internet through such router,
please input the default PSK value for connection.
The WPA encrypts each frame transmitted from the radio using
the key, which either PSK (Pre-Shared Key) entered manually
in this field below or automatically negotiated via 802.1x
authentication. Either 8~63 ASCII characters, such as
012345678(or 64 Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
Type - Select from Mixed (WPA+WPA2) or WPA2 only.
Pre-Shared Key (PSK) - Either 8~63 ASCII characters, such as
012345678..(or 64 Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
64-Bit - For 64 bits WEP key, either 5 ASCII characters, such
as 12345 (or 10 hexadecimal digitals leading by 0x, such as
0x4142434445.)
128-Bit - For 128 bits WEP key, either 13 ASCII characters,
such as ABCDEFGHIJKLM (or 26 hexadecimal digits leading
by 0x, such as 0x4142434445464748494A4B4C4D).
All wireless devices must support the same WEP encryption bit
size and have the same key. Four keys can be entered here, but
only one key can be selected at a time. The keys can be entered
in ASCII or Hexadecimal. Check the key you wish to use.
n t r o l
n t r o l
208
Vigor2930 Series User's Guide
