st
1 Subnet Mask
DHCP Server
DNS
WAN1/WAN2 ---
Link Status
MAC Address
Connection
IP Address
Default Gateway
Wireless LAN ---
MAC Address
Frequency Domain
Firmware Version
igor2930 Series User's Guide
Display the subnet mask address of the LAN interface.
Display the current status of DHCP server of the LAN
interface.
Display the assigned IP address of the primary DNS.
Display the connection status.
Display the MAC address of the WAN Interface.
Display the connection mode used currently.
Display the IP address of the WAN interface.
Display the assigned IP address of the default gateway.
Display the MAC address of the wireless LAN.
It can be Europe (13 usable channels), USA (11 usable
channels) etc. The available channels supported by the
wireless products in different countries are various.
It indicates information about equipped WLAN miniPCi
card. This also helps to provide availability of some
features that are bound with some WLAN miniPCi card.
225
