INTERFACE mode
ip address
• Enable the interface.
INTERFACE mode
no shutdown
Example of Error Due to Issuing a Layer 3 Command on a Layer 2 Interface
If an interface is in the incorrect layer mode for a given command, an error message is displayed (shown in
bold). In the following example, the ip address command triggered an error message because the interface
is in Layer 2 mode and the ip address command is a Layer 3 command only.
Dell(conf-if)#show config
!
interface TengigabitEthernet 1/2
no ip address
switchport
no shutdown
Dell(conf-if)#ip address 10.10.1.1 /24
% Error: Port is in Layer 2 mode Te 1/2.
Dell(conf-if)#
To determine the configuration of an interface, use the show config command in INTERFACE mode or the
various show interface commands in EXEC mode.

Configuring Layer 3 (Interface) Mode

To assign an IP address, use the following commands.
• Enable the interface.
INTERFACE mode
no shutdown
• Configure a primary IP address and mask on the interface.
INTERFACE mode
ip address ip-address mask [secondary]
The ip-address must be in dotted-decimal format (A.B.C.D) and the mask must be in slash format (/xx).
Add the keyword secondary if the IP address is the interface's backup IP address.
Example of the show ip interface Command
You can only configure one primary IP address per interface. You can configure up to 255 secondary IP
addresses on a single interface.
To view all interfaces to see with an IP address assigned, use the show ip interfaces brief command in
EXEC mode as shown in
To view IP information on an interface in Layer 3 mode, use the show ip interface command in EXEC
Privilege mode.
View Basic Interface Information.
