so that the DHCP snooping table can decrease in size. After the table usage falls below the maximum limit of
4000 entries, new IP address assignments are allowed.
To view the number of entries in the table, use the show ip dhcp snooping binding command. This
output displays the snooping binding table created using the ACK packets from the trusted port.
Dell#show ip dhcp snooping binding
Codes : S - Static D - Dynamic
IP Address MAC Address
================================================================
10.1.1.251 00:00:4d:57:f2:50
10.1.1.252 00:00:4d:57:e6:f6
10.1.1.253 00:00:4d:57:f8:e8
10.1.1.254 00:00:4d:69:e8:f2
Total number of Entries in the table : 4

Dynamic ARP Inspection

Dynamic address resolution protocol (ARP) inspection prevents ARP spoofing by forwarding only ARP frames
that have been validated against the DHCP binding table.
ARP is a stateless protocol that provides no authentication mechanism. Network devices accept ARP requests
and replies from any device. ARP replies are accepted even when no request was sent. If a client receives an
ARP message for which a relevant entry already exists in its ARP cache, it overwrites the existing entry with the
new information.
The lack of authentication in ARP makes it vulnerable to spoofing. ARP spoofing is a technique attackers use
to inject false IP-to-MAC mappings into the ARP cache of a network device. It is used to launch man-in-the-
middle (MITM), and denial-of-service (DoS) attacks, among others.
A spoofed ARP message is one in which the MAC address in the sender hardware address field and the IP
address in the sender protocol field are strategically chosen by the attacker. For example, in an MITM attack,
the attacker sends a client an ARP message containing the attacker's MAC address and the gateway's IP
address. The client then thinks that the attacker is the gateway, and sends all internet-bound packets to it.
Likewise, the attacker sends the gateway an ARP message containing the attacker's MAC address and the
client's IP address. The gateway then thinks that the attacker is the client and forwards all packets addressed
to the client to it. As a result, the attacker is able to sniff all packets to and from the client.
Other attacks using ARP spoofing include:
Broadcast An attacker can broadcast an ARP reply that specifies FF:FF:FF:FF:FF:FF as the gateway's
MAC address, resulting in all clients broadcasting all internet-bound packets.
MAC flooding An attacker can send fraudulent ARP messages to the gateway until the ARP cache is
exhausted, after which, traffic from the gateway is broadcast.
Denial of service An attacker can send a fraudulent ARP messages to a client to associate a false MAC
address with the gateway address, which would blackhole all internet-bound packets
from the client.
Expires(Sec) Type VLAN
172800 D
172800 D
172740 D
172740 D
Dynamic Host Configuration Protocol (DHCP)
Interface
Vl 10 Te 0/2
Vl 10 Te 0/1
Vl 10 Te 0/3
Vl 10 Te 0/50
