xStatus Video Layout Site [n] Output [1..2] Frame [1..6] VideoSourceId
Shows the video source Id which is used when adding or updating frames. See the xCommand
Video Layout Frame Add and xCommand Video Layout Frame Update.
Value space of the result returned:
<1..2>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 VideoSourceId
*s Video Layout Site 1 Output 1 Frame 1 VideoSourceId: 0
** end
xStatus Video Layout Site [n] Output [1..2] Frame [1..6] InputNumber
Shows the layout input number.
Value space of the result returned:
<1..2>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 InputNumber
*s Video Layout Site 1 Output 1 Frame 1 InputNumber: 0
** end
xStatus Video Layout Site [n] Output [1..2] Frame [1..6] Filename
Shows the filename of the layout frame.
Value space of the result returned:
<String>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 Filename
*s Video Layout Site 1 Output 1 Frame 1 Filename: "/user/posters/wallpaper.png"
** end
Codec C20 API Reference Guide TC7.0, JANUARY 2014.
D14869.11
About the API xConfiguration
xStatus Video Layout Site [n] Output [n] Frame [n] VideoSourceContent
xStatus Video Layout Site [n] Output [n] FrameContainer [n] PositionX
184
xCommand
Shows the video source content type of each layout frame.
noSource: There is no source.
black: The frame is black.
main: The frame displays the main image from a local or a remote user.
self-view: The frame displays the self-view image.
selfviewPip: The frame displays the self-view image in PiP format.
speaker: The frame displays the image of the speaker.
speakerPip: The frame displays the image of the speaker in PiP format.
presentation: The frame displays the image of the presentation.
presentationPip: The frame displays the image of the presentation in PiP format.
presentationPreview: The frame displays the preview image of the presentation.
localInput: The frame displays the image of the local input source.
wallpaper: The frame displays the wallpaper.
gui: The frame displays the user interface.
internal: For internal use.
Value space of the result returned:
<noSource/black/main/selfview/selfviewPip/speaker/speakerPip/presentation/presentationPip/
presentationPreview/localInput/wallpaper/gui/internal>
Example:
xStatus Video Layout Site Output Frame VideoSourceContent
*s Video Layout Site 1 Output 1 Frame 1 VideoSourceContent: wallpaper
*s Video Layout Site 1 Output 2 Frame 1 VideoSourceContent: wallpaper
*s Video Layout Site 1 Output 3 Frame 1 VideoSourceContent: wallpaper
*s Video Layout Site 1 Output 3 Frame 2 VideoSourceContent: gui
*s Video Layout Site 1 Output 4 Frame 1 VideoSourceContent: wallpaper
*s Video Layout Site 1 Output 5 Frame 1 VideoSourceContent: wallpaper
** end
For internal use only.
Value space of the result returned:
<Integer>
