Standby configuration
xConfiguration Standby Control
Determine whether the system should go into standby mode or not.
Requires user role: ADMIN
Value space: <Off/On>
Off: The system will not enter standby mode.
On: Enter standby mode when the Standby Delay has timed out. Requires the Standby Delay to be
set to an appropriate value.
Example: xConfiguration Standby Control: On
xConfiguration Standby Delay
Define how long (in minutes) the system shall be in idle mode before it goes into standby mode.
Requires the Standby Control to be enabled.
Requires user role: ADMIN
Value space: <1..480>
Range: Select a value from 1 to 480 minutes.
Example: xConfiguration Standby Delay: 10
xConfiguration Standby BootAction
Define the camera position after a restart of the codec.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/Preset8/
Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/RestoreCameraPosition/
DefaultCameraPosition>
None: No action.
Preset1 to Preset15: After a reboot the camera position will be set to the position defined by the
selected preset.
RestoreCameraPosition: After a reboot the camera position will be set to the position it had before
the last boot.
DefaultCameraPosition: After a reboot the camera position will be set to the factory default
position.
Example: xConfiguration Standby BootAction: DefaultCameraPosition
SX20 Codec API Reference Guide TC7.0, JANUARY 2014.
D14949.08
About the API xConfiguration xConfiguration
xConfiguration Standby StandbyAction
xConfiguration Standby WakeupAction
60
xCommand
Define the camera position when going into standby mode.
Requires user role: ADMIN
Value space: <None/PrivacyPosition>
None: No action.
PrivacyPosition: Turns the camera to a sideways position for privacy.
Example: xConfiguration Standby StandbyAction: PrivacyPosition
Define the camera position when leaving standby mode.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/Preset8/
Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/RestoreCameraPosition/
DefaultCameraPosition>
None: No action.
Preset1 to Preset15: When leaving standby the camera position will be set to the position defined
by the selected preset.
RestoreCameraPosition: When leaving standby the camera position will be set to the position it
had before entering standby.
DefaultCameraPosition: When leaving standby the camera position will be set to the factory default
position.
Example: xConfiguration Standby WakeupAction: RestoreCameraPosition
