328/341 Bosch Rexroth AG
Appendix
Type
MSK101C-0200-FN-__-___-
____
MSK101D-0200-FN-__-___-
____
MSK101E-0200-FN-__-___-
____
MSK103A-0300-NN-__-___-
____
MSK103B-0300-NN-__-___-
____
MSK103D-0300-NN-__-___-
____
MSK131B-0200-NN-__-___-
____
MSK131D-0200-NN-__-___-
____
11.3.2

Leakage Capacitance of Power Cables

Leakage capacitance of the component
C
ab
nF
6,2
13,2
15,2
1,5
2,1
6,0
14,3
27,7
Tab. 11-8: MSK - Leakage Capacitance (Excerpt)
See also Rexroth IndraDyn - Technical Data.
The power cables (bulk cables) of the "RKL" line by Rexroth have the capaci‐
tances per unit length listed below. The values refer to the sum of the single
capacitances of power cores 1, 2 and 3 against the overall shield.
See also Rexroth Connection Cables - Data Sheet Bulk Cables.
Data Sheet Excerpt- Bulk Cables
Type
INK0653
INK0650
INK0602
INK0603
INK0604
INK0605
INK0606
INK0607
DOK-INDRV*-HCS01******-PR05-EN-P
Rexroth IndraDrive CsDrive Systems with HCS01
Last modification: 2012-09-17
Cross section of power core Leakage capacitance
mm
2
1,0
1,5
2,5
4,0
6,0
10,0
16,0
25,0
C
Y_K_typ
nF/m
0,6
0,8
0,7
0,8
0,8
1,0
1,2
1,1
