I/O System
7-15.
lOP CONTROL.
The lOP control block represents
sequencing
logic
for
transfers
between the device and memory, and between
the device and the CPU. Each
of
the
1 ines
shown
ente ring
or
leaving
this
block are discussed with their associated transfer
sequences.
7-16.
INTERRUPT CONTROL.
The interrupt
control
logic
accepts
an Interrupt Request
(INTREQ) from the Device COntrollers on the
lOP Bus, interrogates the Device Controllers with INTPOLL to find
the
highest-priority request,
and,
when Interrupt
Acknowledge
(INTACK)
is received,
loads the device address into the lOA Reg-
ister.An External Interrupt (EXTlNT) signal is issued to the
cpu.
7-17.
INT OEVNO.
The
I/O
Address
(lOA)
Register
holds
the
device
number
of the interrupting device so that, upon command,
the CPU can read
the
contents
onto
the
S-Bus
for
interrupt
pr oces sing.
are
two
data
output
for memory data
received
Register for direct
data
Signals from lOP
control
the lOP Bus or transfer the
entr y.
7-18.
DATE
OUTPUT
REGISTERS.
There
reg i ste r s,
the lOP
Oa ta Out Registe r
from the CTL Bus,
and the
100
Data Out
received via the
U-Bus from the CPU.
can either read the contents out onto
contents into MUX for restoring a DRT
7-19.
DATA INPUT REGISTERS.
There are two input registers.
The
lOP Data In
Register is used for sending data to memory via
the
CTL Bus.
This register is loaded from either the lOP Bus or, for
DRT entry restoring, from the lOP Data Out Register.
When doing
a ORT store,
the lOP Da ta In Registe r is
incremented by two be-
fore the transfer is made.
The second input register,
IOD Data
In,
may be
used either as a direct data input register
or as a
memory address register.
It is loaded from the lOP Bus.
During
direct I/O execution, the register contents are read onto the
cpu
S-Bus.
When addressing memory,
the register contents are
read
out to the CTL Bus.
7-20. Module Control Unit
As previously discussed in Sections II and VI, the Module Cbntrol
Unit (figure 6-1)
contains MCUs for both the
CPU
and the
lOP.
The
MCUs
operate basically in parallel,
but not independently.
Since both
MCUs
share the same access to the CTL Bus,
and also
share the same module number, it is necessary to resolve priority
when both' the lOP and CPU simultaneously attempt to use the
bus.
Priority is
resolved so that
lOP
requests take precedence over
CPU requests except that a CPU high request takes precedence over
an lOP low request.
This exception means that the CPU is in the
middle
of a
memory write operation,
having sent an
address to
memory,
and the high request is an attempt to follow up by send-
ing the data.
CPU
low request represents
the beginning
of a
transfer
(attempt to send an address) and any
lOP
request will
have priority over the CPU low request.
7-1R
