G.SHDSL WICs
Table 15
LED
OK LED
LINK
(CD) LED
Supported Platforms
Table 16
WIC-1SHDSL-V2 interface card.
Table 16
Mode
2-wire ATM
2-wire T1/E1 in back-to-back
configurations
4-wire ATM
OL-12846-01
4
G.SHDSL WIC LEDs (continued)
Color Description
Green Enabled when the card is detected by the router.
Green Green when cells or frames are passing between the host and the DSLAM.
and Yellow when the T1E1 framer detects an alarm. Applies only to the
Yellow WIC-1SHDSL-V2 and WIC-1SHDSL-V3 interface cards.
lists the Cisco router platforms that are compatible with each mode available on the
Cisco router platforms compatible with WIC-1SHDSL-V2 interface card
Cisco Platforms
• Cisco 1721
• Cisco 1751
Cisco 1760
•
Cisco 1841
•
Cisco 26xxXM
•
Cisco 2691
•
Cisco 28xx
•
Cisco 3631
•
• Cisco 37xx
Cisco 38xx
•
Cisco 1721
•
Cisco 1751
•
Cisco 1760
•
Cisco 26xxXM
•
• Cisco 1721
• Cisco 1751
Cisco 1760
•
Cisco 1841
•
Cisco 26xxXM
•
Cisco 2691
•
Cisco 28xx
•
Cisco 3631
•
• Cisco 37xx
Cisco 38xx
•
DSL Interface Cards
