Upgrading a Cisco TelePresence System 3000 to
a Cisco TelePresence System 3200
Revised: July 28, 2008, OL-16441-01

Upgrading a CTS-3000 to a CTS-3200: Summary Steps

The following are the summary steps that you perform to upgrade a CTS-3000 system to a CTS-3200
system. Detailed information about the steps you perform are referenced in these steps.
For room and other minimum installation requirements, refer to the
Note
Data
System 3200 Assembly, Use & Care, and Field Replacement Unit
The table segments are unstable during assembly. Use caution, and support all structures as required.
Caution
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Table elements are heavy, and metal edges can be very sharp. Protect your hands and eyes from injury
Caution
by wearing safety gloves and glasses.
In order to prevent scratching the table tops, you should avoid putting any tools on the shelf surfaces.
Caution
The directions left and right refer to the assembly as you face it from the front.
Note
OL-16441-01
Sheet. For more information about installing a CTS-3200, refer to the
5
C H A P T E R
Cisco TelePresence System 3200
Cisco TelePresence
Guide.
Cisco TelePresence System
5-1
