Step 6 Reattach the right handle/mounting bracket to the codec assembly.
Figure 1-6 Right Handle/Mounting Bracket and Codec Assembly
8
1
Access the CTS-500 codec by performing one of the following actions:
Step 7
•
•
Removal is the opposite of installation; it can be helpful to review the codec installation instructions in
Tip
the
Cisco TelePresence System
1-8
8
For a pedestal stand-mounted CTS-500, lift and remove the codec cover. See Figure 2-14 for more
information.
For a wall-mounted or table stand-mounted CTS-500, remove the codec handle, slide the codec to
the center, and disconnect the codec from the base.
Cisco TelePresence System 500 Assembly, Use & Care, and Field Replaceable Unit
Chapter 1 Options for the Cisco TelePresence System 500
2
Guide.
