4.12 Access Control Descriptions and Functions

This section describes the "Access Control" page of the iServers's Web interface
(although some of the items of this page where described in previous Section 4.2). This
page allows the users to set up the network and security parameters of the iServer.
To get into the Access Control page, the user will be prompted with an Admin Password.
The default Admin password is 00000000 and is changeable, if desired.
ACCESS CONTROL
Address
Login Password: This allows users to access and modify the "Configuration/Device Setup"
page. The default password is 12345678. This password can be up to 16 alpha-numeric case-
sensitive characters. If there is no password assigned (blank box) the iServer will not require
password to access and modify the "Configuration Setup" page.
Admin (administrator) Password: This allows users to access and modify the "Access
Control" page. The default password is 00000000. This password can be up to 16
alphanumeric case-sensitive characters. If there is no password assigned (blank box) the
iServer will not require password to access and modify the "Access Control" page.
Host Name: Refer to Section 3.4, DNS.
MAC Address: This is also called Hardware address or Ethernet address, which is
assigned to the iServer at production. The MAC (Media Access Control) address is the
iServer's unique hardware number and is not changeable.
IP Address: The IP (Internet Protocol) address is a 32-bit number that identifies each
sender or receiver of information that is sent in packets across the Ethernet or the
Internet. The iServer's default IP address is 192.168.1.200. The iServer's IP address
should be changed to fit user's networking environment. Consult with your IT department
for obtaining an IP address.
The DHCP will be enabled in the iServer if its IP address is set to 0.0.0.0. The
DHCP can also be enabled by setting the dip switch number 3 to ON position.
http://192.168.1.200
ACCESS CONTROL
Login Password 12345678
Admin Password 00000000
Host Name
MAC Address 00:03:03:00:21:D9
IP Address 192.168.1.200
Gateway Address
Subnet Mask

Figure 4.28 Access Control

eis21d9
0.0.0.0
255.255.255.0
Save Reset
Power Recycle
Main Menu
