4.2 Setting a New IP Address over the Network

Besides using the iCONNECT software, you may use the iServer's default IP address to

access it and assign a new IP address to it.

The iServer is shipped with a default IP address of 192.168.1.200 and Subnet Mask of

255.255.255.0. You can configure your PC's Network connection with an IP address that

is in the same range as the iServer's IP address (192.168.1.x) and connect to the iServer

using a crossover network cable between your PC and the iServer.

With this completed, you can go to the DOS-Prompt and ping 192.168.1.200. If you

receive responses back (Figure 4.1), you can go to a Web browser and type in

http://192.168.1.200 and it will take you to the iServer's main web page.

Select Access Control button, you'll be asked for the password. The default Login

password is "12345678" and the Admin password is "00000000", then you should be on

the Access Control page were you can simply type in the desired Static IP address, and

click Save.

ACCESS CONTROL

Address

For the IP address to take effect, the iServer needs to be turned OFF/ON or pressing the

physical button marked "RESET" on the iServer

You can now connect the iServer to an Ethernet hub using a straight through cable,

power it up, and follow the ping routine mentioned in the previous section.

Refer to Section 4.12 for detailed descriptions and functions of the Access

Control Page.

http://192.168.1.200

ACCESS CONTROL

Admin Password 00000000

Host Name

MAC Address 00:03:03:00:21:D9

IP Address 192.168.1.200

Gateway Address

Subnet Mask

eis21d9

0.0.0.0

255.255.255.0

Save Reset

Power Recycle
