4.7.1.2 Totalizer Mode

This mode is operated commonly as event counter or recorder as either with single A or
B channel or If there are dual inputs, both Input values will be totalized or accumulated
and displayed graphically and digitally until Reset Timer Button restart measurement of
both Channels at zero or the Offset values.
However Users must readjust Max. or Min. Range Values between measurement values
to keep Line Chart fully displaying as once reset executed. Device now is UP & DOWN
32-bit Counter ranging between (–2147483647 and +2147483647). Users must access
Configuration Page to setup device for this mode.
For Totalizer Mode ID, observe Message Item Window and notice items following:
a= Totalizer
c=CH A input count reading value is totalizing: CH A Total count
d=CH B input count reading value is totalizing: CH B Total count
For Example: To compare and monitor PCB (Printed Circuit Board) Assembling
Productivities of 2 machines or 2 types of product with specified time period by selecting
suitable x- Axis Time Scale Option according to your company's demand, Figure 4.10 is
one of example, this device offers the most typical and user-friendly illustration and
clarity as setup with this Totalizer Mode.
Make certain that Debounce Time must be zero when operating with
frequency signals.
