4.7.1.6 Quadrature Mode (continued)
SERVER HOME PAGE
http://192.168.1.200
Assembly Dept.
SP1 200 SP2 100
Motion Monitor
CH A: 97574 PPR CH B: 1138 PPR
Chart
-10000 100000
Message:
1Minute(1Sec/Div)
Mon Nov 24 15:24:05 PST 2003 Mon Nov 24 15:57:43 PST 2003
a=Quadrature ;b=0;c=95228;d=1138;e=Motion Monitor;f=PPR;g=011;h=200;i=100;j=2;k=0;l=/;m=12:50:03 Nov,22 2003;
a=Quadrature ;b=0;c=96411;d=1138;e=Motion Monitor;f=PPR;g=011;h=200;i=100;j=2;k=0;l=/;m=12:50:03 Nov,22 2003;
a=Quadrature ;b=0;c=97574;d=1138;e=Motion Monitor;f=PPR;g=011;h=200;i=100;j=2;k=0;l=/;m=12:50:03 Nov,22 2003;
Reset Timer Reset Latch A Reset Latch B
Applet pulse started

Figure 4.14 Example of Quadrature Mode

33
