4.7.2 SetPoint, Alarm and Alarm Output Operation Configuration
To setup Alarm1 / Alarm2 operations or Batches' values and access Configuration Page.
Locate the section as illustrated in Figure 4.16:
Figure 4.16 Example of SetPoint / Alarm Configuration Section
Any edited/modified value with decimal point must be matched with existing
Decimal Point setting in Operation Condition Parameters Section 4.7.4.1.11 of
Configuration Page.
4.7.2.1 SP1 Value
Enter desired value for Alarm1 Setpoint or A Batch and its factory default value is 0.
Whatever number is entered for modifying The SP1 Value or A Batch will be displayed in
exponential format after SAVE button is pressed or clicked.
4.7.2.2 SP1 Latch Mode
Select either "Unlatch" (as default option) for unlatched Alarm1 operation or "Latch" for
latched Alarm1 operation.
4.7.2.3 SP1 Active Mode
Set device alarm activation Above (as default option) or Below SetPoint 1 value.
4.7.2.4 SP1 Dead Band
Enter desired value of Alarm1 Dead Band.
4.7.2.5 SP1 Active Status
Select the logic normal-state of Alarm1 Output and its factory default value is High.
5.00000000e+03
SP1 Value
SP1 Latch Mode
SP1 Active Mode
SP1 Dead Band
SP1 Active Status
4.00000000E+03
SP2 Value
SP2 Latch Mode
SP2 Active Mode
SP2 Dead Band
SP2 Active Status
Unlatch
Above
0
High
Unlatch
Above
0
High
Save
36
