4.6.1 Chart Descriptions (continued)
E)
Chart Option Pull-Down Menu, which allows users to select Bar chart type Figure 4.8
or Line chart type Figure 4.9.
F)
Graphical Display of Chart, either Bar or X-axis Line Chart.
G)
Enter your setting for Minimum Range of Measurement for graphical display.
H)
Enter your setting for Maximum Range of Measurement for graphical display.
Those two settings will reset to default (100 max. and 0 min.) if there is any
change made from Configuration or Chart refresh. To modify, just type in the
desired values and simply hit enter key.
J1) The square dot will flash between 2 colors red & green as representing a Network
Communication Activity Indicator as device successfully connecting otherwise
remaining red if there is problem with connection or Network disconnected.
J2) Start Date and Time of the Experiment / Measurement Task.
J3) X-Axis Time Scale Option Pull-Down Menu for Line Chart. There are 6 options
available to users as the following:
1 Minute (1 Second/Div)
1 Hour (1 Minute/Div)
1 Day (1 Hour/Div)
1 Week (1 Day/Div)
1 Month (1 Day/Div)
1 Year (1 Month/Div).
J4) Current Date and Time of the Experiment/Measurement Task. It is synchronized
with users' operating system.
Any modification or change that is made and saved from Configuration Page will
restart the Chart.
