4.5.1 Browser Proxy Selection
Accessing iServer units within your internal network
•
Usually when the computer and iServer are on an internal network, you will not use
Proxy server access.
•
You should un-check the "Use Browser Settings" option on the "Proxy" tab.
Accessing iServer units using the internet
•
Often the web browser will use Proxy server access to the internet. In such cases,
the default Java runtime settings on the "Proxy" tab should suffice. The default
setting is the "Use Browser Settings" option.
•
If the default proxy setting doesn't work, then you may have a situation where the
proxy settings of the web browser are incorrect.
Diagnostics:
If the web page of the iServer appears, then the HTTP Proxy is working fine.
If the data isn't updated on the iServer upon selecting the Read Sensor web page, there
may be a problem with access through a winsock proxy server. In such cases your network
administrator will need to provide the winsock proxy server and port #s. (If the administrator
requires knowledge of the port # required on the iServer, the value is 2003).
These values should be entered into the Socks line on the "Proxy" tab (of the Java Plugin
control panel) or into the "connections" tab on the View,Internet Options dialog and make
sure that the Proxy tab shows that the "Use Browser Settings" option is not selected (i.e.
when you specify proxy connections in the Java Plugin control panel.
Accessing iServer units over Peer-to-Peer network
A simple peer-to-peer network is setup by disconnecting from the main network (as users
will often do when trying to do initial setup of the iServer) and then connecting the iServer
to another computer using a ethernet hub, an ethernet switch, or a Cross-over cable
connection.
Often when using a peer-to-peer network, the Java plugin and the web browser (such as
Internet Explorer) have internet connections configured to connect through proxy servers.
In such case, you will need to simply assign the final IP address on this peer to peer
network and then view the iServer charts after connecting the iServer into the regular
network. Otherwise you can disable the Java plug-in's "Use Browser Settings" temporarily
and then reconfigure the Java plug-in settings for regular network access after testing the
iServer chart access on your peer-to-peer network.
The "Use Browser Settings" should not be selected. And the HTTP and Socks proxy
entries should be blank. Also, setup the internet browser so that proxy servers are disabled.
Java and the Java Coffee Cup Logo are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries."
If you still have problems viewing the page and you are on a Proxy Server or are
behind a Firewall, please contact your MIS administrator to verify that you have
the lastest Proxy Client Software, version 2.0 or higher.
