Page 1: Washing Machine
Washing Machine WNF 5200 User‘s Manual Document Number 2820524301/ 03-09-14.(10:22) - Page 2 Please read this user manual first! Dear Customer, Thank you for prefering an Blomberg product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important instructions for safety and 5.8 Spin speed selection....23 environment 5.9 Programme and consumption table..24 5.10 Auxiliary function selection . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 5: Intended Use
Important instructions for safety and environment • Use detergents, softeners and supplements suitable for automatic washing machines only. • Follow the instructions on the textile tags and on the detergent package. • The product must be unplugged during installation, maintenance, cleaning and repairing procedures. • Always have the installation and repairing procedures carried out by the Authorised Service Agent. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unAuthorised persons. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similary qualified persons in order to avoid a hazard. • If the power cable is damaged, it must be replaced by the manufacturer, after sales service or a similarly qualified person (preferably an electrician) or someone designated by the importer in order to avoid possible risks. -
Page 6: Children's Safety
Important instructions for safety and environment 1.3 Children's safety • Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children. • Electrical products are dangerous for the children. Keep children away from the product when it is in use. Do not let them to tamper with the product. Use child lock to prevent children from intervening with the product. • Do not forget to close the loading door when leaving the room where the product is located. -
Page 7: Package Information
Important instructions for safety and environment 1.4 Package information • Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities. -
Page 8: Your Washing Machine
Your washing machine 2.1 Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Blomberg Model name WNF5200 Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) -
Page 9: Overview
Your washing machine 2.2 Overview 1- Power cable 2- Top panel 3- Control panel 4- Filter cap 5- Adjustable feet 6- Loading door 7- Detergent drawer 8- Drain hose 9 / EN Washing Machine /User’s Manual... -
Page 10: Package Contents
Your washing machine 2.3 Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronical water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual... -
Page 11: Installation
Installation Refer to the nearest Authorised Service Agent for installation of the product. To make the product ready for use, review the information in the user manual and make sure that the electricity, tap water supply and water drainage systems are appropriate before calling the Authorised Service Agent. -
Page 12: Connecting Water Supply
Installation Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future. Never move the product without the transportation safety bolts properly fixed in place! 3.4 Connecting water supply 3. Open the taps completely after making the The water supply pressure required to run the hose connection to check for water leaks at product is between 1 to 10 bars (0.1 –... -
Page 13: Adjusting The Feet
Installation 1. Loosen the lock nuts on the feet by hand. 2. Adjust the feet until the product stands level • To prevent flowing of dirty water back into the and balanced. machine and to allow for easy discharge, do not immerse the hose end into the dirty water or do not drive it in the drain more than 15 cm. - Page 14 Installation 1 Connect the green - yellow or green (earth) wire WARNING: Damaged power cables must be to the terminal in the plug marked ‘E’ or with replaced by the Authorised Service Agents. the symbol f or coloured green and yellow or green.
-
Page 15: Preparation
Preparation 4.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying Suitable for No Iron Do not dry- Sensitive / Do not dry Do not dry Symbols dryer clean Delicate dry with dryer DRYING... -
Page 16: Preparing Laundry For Washing
Preparation 4.2 Preparing laundry for washing but do not overload; see, "Programme and consumption table". • Laundry items with metal attachments such as, • Always follow the instructions on the detergent underwired bras, belt buckles or metal buttons packaging. will damage the machine. Remove the metal • Wash slightly soiled laundry at low pieces or wash the clothes by putting them in a temperatures. -
Page 17: Correct Load Capacity
Preparation 4.5 Correct load capacity The maximum load capacity depends on the type of laundry, the degree of soiling and the washing programme desired. The machine automatically adjusts the amount of water according to the weight of the loaded laundry. WARNING: Follow the information in the Detergent, softener and other cleaning agents... - Page 18 Preparation Adjusting detergent amount Using gel and tablet detergent The amount of washing detergent to be used Apply the following instructions when using tablet, depends on the amount of laundry, the degree of gel and similar detergents. soiling and water hardness. • If the gel detergent thickness is fluidal and • Do not use amounts exceeding the dosage your machine does not contain a special liquid...
- Page 19 Preparation • Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not pour the bleaching agent onto the clothes and do not use it for coloured clothes. • When using oxygen based bleaches, select a programme that washes at a lower temperature.
-
Page 20: Tips For Efficient Washing
Preparation 4.8 Tips for efficient washing Clothes Light colours and Delicates/ Colours Dark colours whites Woollens/Silks (Recommended (Recommended (Recommended (Recommended temperature range temperature range temperature range temperature range based on soiling level: based on soiling level: based on soiling based on soiling 40-90ºC) cold-40ºC) level: cold-40ºC) -
Page 21: Operating The Product
Operating the product 5.1 Control panel 1 - Programme Selection knob (Uppermost 4 - Spin Speed adjustment button position On/Off) 5 - Auxiliary Function buttons 2 - Programme Follow-up indicator 6 - Delayed Start button (in some models) 3 - Temperature Adjustment button 7 - Start / Pause button 5.2 Preparing the machine 1. -
Page 22: Main Programmes
Operating the product 5.4 Main programmes economical wash. This feature is available for certain models having remaining time display. Depending on the type of fabric, use the following main programmes. • Hygiene • Cottons Use this programme to wash baby laundry, and Use this programme for your cotton laundry (such the laundry that belongs to allergic persons. -
Page 23: Special Programmes
Operating the product 5.6 Special programmes 5.8 Spin speed selection For specific applications, select any of the Whenever a new programme is selected, the following programmes. recommended spin speed of the selected • Rinse programme is displayed on the spin speed indicator. -
Page 24: Programme And Consumption Table
Operating the product 5.9 Programme and consumption table Auxiliary functions Programme Temperature Cottons 2.25 1600 • • • • • • Cold-90 Cottons 1.45 1600 • • • • • • Cold-90 Cottons 0.85 1600 • • • • • • Cold-90 Cottons Eco 60**... - Page 25 Operating the product ** “Cotton eco 40°C and Cotton eco 60°C are standard cycles.” These cycles are known as ‘40°C cotton standard cycle’ and ‘60°C cotton standard cycle’ and indicated with the symbols on the panel. The auxiliary functions in the table may vary according to the model of your machine. Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
-
Page 26: Auxiliary Function Selection
Operating the product times and also the number of rinsing steps for You can see the washing time of the programme you have selected on the display of the machine. It is lightly soiled laundry. normal that small differences may occur between the time shown on the display and the real washing When you select this function, load time. -
Page 27: Starting The Programme
Operating the product 5.11 Starting the programme 2. Select the washing programme, temperature, spin speed and, if required, the auxiliary 1. Press Start / Pause button to start the functions. programme. 3. Set the desired time by pressing the Delayed 2. -
Page 28: Progress Of Programme
Operating the product To deactivate the Child Lock: If the level is unsuitable, Loading Door light turns off and the loading door cannot be opened. If Press and hold 1st and 2nd auxiliary function you are obliged to open the Loading Door while buttons for 3 seconds while any programme is the Loading Door light is off, you have to cancel running. -
Page 29: Canceling The Programme
Operating the product 5.16 Canceling the programme To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be canceled. End / Cancel light will flash continuously to notify that the programme has been canceled. Your machine will end the programme when you turn the Programme Selection knob;... -
Page 30: Maintenance And Cleaning
Maintenance and cleaning Service life of the product extends and frequently If your detergent drawer is the one indicated in the faced problems decrease if cleaned at regular following figure: intervals. 6.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 31: Cleaning The Body And Control Panel
Maintenance and cleaning Repeat Drum Cleaning process in every 2 months. Use an anti-limescale suitable for the washing machines. After every washing make sure that no foreign substance is left in the drum. 1. Close the taps. 2. Remove the nuts of the water intake hoses to access the filters on the water intake valves. - Page 32 Maintenance and cleaning In order to clean the dirty filter and discharge the water: 1. Unplug the machine to cut off the supply power. WARNING: Temperature of the water inside the machine may rise up to 90 ºC. To avoid burning risk, filter must be cleaned after the water in the machine cools down.
-
Page 33: Troubleshooting
Troubleshooting Problem Reason Solution Programme cannot be Washing machine has switched to self Š Press and hold Start / Pause / Cancel protection mode due to a supply problem (line button for 3 seconds to reset the machine started or selected. voltage, water pressure, etc.). - Page 34 Troubleshooting Problem Reason Solution Washing takes longer Water pressure is low. Š Machine waits until taking in adequate amount of water to prevent poor washing time than specified in the quality due to the decreased amount manual.(*) of water. Therefore, the washing time extends.
- Page 35 Troubleshooting Problem Reason Solution Washing performance is Insufficient amount of detergent has been Š Use the recommended amount of used over a long period of time. detergent appropriate for water hardness poor: Laundry turns gray. and the laundry. (**) Washing was made at low temperatures for Š...
- Page 36 Troubleshooting Problem Reason Solution It does not rinse well. The amount, brand and storage conditions of Š Use a detergent appropriate for the the detergent used are inappropriate. washing machine and your laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
-
Page 37: Detergent Drawer
Troubleshooting Problem Reason Solution Detergent residue in the Detergent is put in wet drawer. Š Dry the detergent drawer before putting in detergent. detergent drawer. (**) Detergent has gotten damp. Š Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. - Page 38 Troubleshooting Problem Reason Solution Foam is overflowing from Too much detergent is used. Š Mix 1 tablespoonful softener and ½ l water and pour into the main wash the detergent drawer. compartment of the detergent drawer. Š Put detergent into the machine suitable for the programmes and maximum loads indicated in the “Programme and consumption table”.
- Page 39 39 / EN Washing Machine /User’s Manual...
- Page 40 Blomberg, 36-38 Caxton Way, Watford, Hertfordshire, WD18 8UF Tel: 0800 597 8560 Fax: 0845 6004922 email: service@blomberguk.com www.blomberguk.com...
