- Page 1 Washing Machine WNF 8447 A40 User Manual...
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from the product which has been manufactured in state-of-the-art plants and passed through a strict quality control procedure. Therefore, please read the entire user manual carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your washing machine Main programmes ....19 Additional programmes ... . 19 Overview . -
Page 4: Your Washing Machine
Your washing machine Overview 1- Power cable 5- Adjustable feet 2- Top panel 6- Loading door 3- Control panel 7- Detergent drawer 4- Filter cap 8- Drain hose... -
Page 5: Technical Specifications
Technical specifications Models WNF8447A40 Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Electrical input (V/Hz) 230 V / 50Hz Total current (A) 2200 Total power (W) 1400 Spin speed (rpm max.) 1.40 Stand-by mode power (W) 0.20 Off-mode power (W) Technical specifications may be changed without prior notice to improve the quality of... -
Page 6: Important Safety Instructions
Important safety instructions This section contains safety instructions by a qualified electrician. Our company that will help protect from risk of personal shall not be liable for any damages injury or property damage. Failure to follow that will arise when the product is used these instructions shall void any warranty. -
Page 7: Children's Safety
• The manufacturer waives any responsibility arisen from incorrect usage or transportation. Children's safety • Electrical products are dangerous for the children. Keep children away from the product when it is in use. Do not let them to tamper with the product. Use child lock to prevent children from intervening with the product. -
Page 8: Installation
Installation Refer to the nearest Authorised Service Removing packaging Agent for installation of the product. To reinforcement make the product ready for use, review Tilt the machine backwards to remove the information in the user manual and the packaging reinforcement. Remove the make sure that the electricity, tap water packaging reinforcement by pulling the supply and water drainage systems are... -
Page 9: Connecting Water Supply
3. Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel. (P) Keep the transportation safety bolts in a safe place to reuse when the washing Ensure that the cold and hot water machine needs to be moved again in connections are made correctly when the future. -
Page 10: Adjusting The Feet
• In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure. -
Page 11: First Use
fuse. Connect the green - yellow or green (earth) wire to the terminal in the plug • The specified voltage must be equal to marked ‘E’ or with the symbol f or your mains voltage. coloured green and yellow or green. •... -
Page 12: Disposing Of Packaging Material
Disposing of the old product anti-limescale into the main wash detergent compartment (compartment nr. Dispose of the old product in an II). If the anti-limescale is in tablet form, environmentally friendly manner. put only one tablet into compartment nr. Refer to your local dealer or solid waste II. -
Page 13: Preparation
Preparation Things to be done for energy saving Following information will help you use the product in an ecological and energy- Wash with sensitive, Washing water efficient manner. .short programmes temperature • Operate the product in the highest capacity allowed by the programme you have selected, but do not overload;... -
Page 14: Correct Load Capacity
and the washing programme desired. The machine automatically adjusts the amount of water according to the weight of the loaded laundry. Follow the information in the “Programme and consumption table”. When overloaded, machine’s washing performance will drop. Moreover, noise and vibration problems may occur. Laundry types and their average weights in •... -
Page 15: Using Detergent And Softener
Using detergent and softener • When washing dark coloured clothes and quilts, it is recommended to use Detergent Drawer liquid detergent. The detergent drawer is composed of three • Wash woolens with special detergent compartments: made specifically for woolens. - (1) for prewash Use only detergents manufactured - (2) for main wash specifically for washing machines. - Page 16 detergent between the laundry, close to the lower part of the drum in future washings. Use the tablet or gel detergent without selecting the prewash function. Using starch • Add liquid starch, powder starch or the dyestuff into the softener compartment as instructed on the package.
-
Page 17: Tips For Efficient Washing
Tips for efficient washing Clothes Light colours and Delicates/ Colors Dark colors whites Woolens/Silks (Recommended (Recommended (Recommended (Recommended temperature temperature temperature range temperature range range based range based based on soiling based on soiling level: on soiling level: on soiling level: level: 40-90C) cold-40C) cold-40C) -
Page 18: Operating The Product
Operating the product Control panel Spin Speed Adjustment button Display Temperature Adjustment button Programme Selection knob On / Off button Delayed Start buttons (+ / -) Auxiliary Function buttons Start / Pause / Cancel button Display symbols - Spin Speed indicator - Temperature indicator - Spin symbol - Temperature symbol... -
Page 19: Preparing The Machine
Preparing the machine • Synthetics Use this programme to wash your synthetic 1. Make sure that the hoses are clothes (shirts, blouses, synthetic/cotton connected tightly. blends, etc.). It washes with a gentle action 2. Plug in your machine. and has a shorter washing cycle compared 3. -
Page 20: Temperature Selection
• Hand Wash Use this programme to wash your woolen/ delicate clothes that bear “not machine- washable” tags and for which hand wash is recommended. It washes laundry with a very gentle washing action to not to damage clothes. • Fast Full Load Use this programme to wash your lightly soiled cotton clothes in a short time. -
Page 21: Spin Speed Selection
Spin speed selection 10° and finally, “-” symbol indicating the cold wash option appears on the display. Whenever a new programme is selected, the recommended spin speed of the selected programme is displayed on the spin speed indicator. To decrease the spin speed, press the Spin Speed Adjustment button. -
Page 22: Programme And Consumption Table
Programme and consumption table Auxiliary functions Selectable Programme temperature range °C Cottons 2.60 1600 • • • • • 90-Cold Cottons 1.75 1600 • • • • • 90-Cold Cottons 0.90 1600 • • • • • 90-Cold Bedding 0.75 •... - Page 23 • : Selectable * : Automatically selected, no cancelling. ** : Energy Label programme (EN 60456 Ed.3) *** If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed. - : See the programme description for maximum load.
-
Page 24: Auxiliary Function Selection
Auxiliary function selection F2 appears on the display when you select this function (b). Select the desired auxiliary functions before When you select this function, load starting the programme. Furthermore, you your machine with half of the maximum may also select or cancel auxiliary functions laundry specified in the programme that are suitable to the running programme table. -
Page 25: Time Display
performed with more water (30%) and the Changing the delayed start period pet hair is removed more effectively. If you want to change the time during Never wash your pets in the washing countdown: machine. 1. Press Start / Pause / Cancel button. “:”... -
Page 26: Loading Door Lock
Relevant symbol appears on the display that the machine is paused. Start symbol at the beginning of each programme step disappears. and all symbols remain lit at the end of the programme. The farthermost right symbol indicates the current programme step. Prewash If the Prewash auxiliary function is selected, Prewash symbol appears on the display... -
Page 27: Cancelling The Programme
appears on the display. If you want to spin your laundry when the machine is in this mode: Adjust the spin speed and press Start / Pause / Cancel button. Pause symbol disappears and Start symbol appears. Programme resumes, discharges the water and spins the laundry. -
Page 28: Maintenance And Cleaning
Maintenance and cleaning inside of the bellow with a clean piece of Service life of the product extends and cloth after the programme has come to an frequently faced problems decrease if end. cleaned at regular intervals. Repeat Drum Cleaning process in every Cleaning the detergent drawer 2 months. -
Page 29: Draining Remaining Water And Cleaning The Pump Filter
the water in the machine cools down. 2. Open the filter cap. If the filter cap is composed of two pieces, press the tab on the filter cap downwards and pull the piece out towards yourself. 1. Close the taps. 2. - Page 30 is emptied, repeat the above procedure to drain the water in the machine completely. c. When draining of water is finished, close the end by the plug again and fix the hose in its place. d. Turn the pump filter to take it out. Discharging the water when the product does not have an emergency draining hose:...
-
Page 31: Troubleshooting
Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> Press and hold Start / Pause / Cancel button for 3 seconds to reset the machine to factory settings. (See "Canceling the programme") Water in the machine. - Page 32 Loading door cannot be opened. • Door lock is activated because of the water level in the machine. >>> Drain the water by running the Pump or Spin programme. • Machine is heating up the water or it is at the spinning cycle. >>> Wait until the programme completes.
- Page 33 Machine does not switch to spinning step. • There might be an imbalance of laundry in the machine. >>> Automatic unbalanced load detection system might be activated due to the unbalanced distribution of the laundry in the drum. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
- Page 34 Colour of the clothes faded. • Excessive laundry was loaded in. >>> Do not load the machine in excess. • Detergent in use is damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. •...
- Page 35 Detergent residue in the detergent drawer. • Detergent is put in wet drawer. >>> Dry the detergent drawer before putting in detergent. • Detergent has gotten damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. •...
- Page 36 Laundry remains wet at the end of the programme • Excessive foam might have occurred and automatic foam absorption system might have been activated due to too much detergent usage. >>> Use recommended amount of detergent. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
-
Page 37: Guarantee
Guarantee Your new Blomberg product is guaranteed accordance with the instructions against the cost of breakdown repairs contained in the User Instructions for 3 years from the date of the original Booklet provided. purchase. • Professional installation by a qualified... -
Page 38: Service
Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Blomberg Customer Help-Line. Tel: 0845 604 6859... - Page 40 Blomberg, 36-38 Caxton Way, Watford, Hertfordshire, WD18 8UF Tel: 0845 6048340 Fax: 0845 6004922, email: service@blomberguk.com www.blomberguk.com...
