4 . 3 . 2 S t a t i c R o u t e
4 . 3 . 2 S t a t i c R o u t e
When there are several subnets in LAN, a more effective and quicker way for connection is
static route rather than other methods. Simply set rules to forward data from one specified
subnet to another specified subnet.
4 . 3 . 2 . 1 S t a
4 . 3 . 2 . 1 S t a
The router offers IPv4 and IPv6 for you to configure the static route. Both protocols bring
different web pages.
Each item will be explained as follows:
Item
Add
Edit
Delete
Rename
Refresh
Profile Number Limit
Profile
Enable
Destination IP Address
Subnet Mask
t i c R o u t e
t i c R o u t e
Description
Add a new static route setting.
Modify the selected static route setting.
To edit static route setting, simply select the one you want to
modify and click the Edit button. The edit window will
appear for you to modify the corresponding settings for the
selected rule.
Remove the selected static route setting.
To delete a static route setting, simply select the one you
want to delete and click the Delete button.
Allow to modify the selected profile name.
Renew current web page.
Display the total number of the profiles to be created.
Display the name of such static route.
Display the status of the profile. False means disabled; True
means enabled.
Display the IP address for such static route profile.
Display the subnet mask for such static route profile.
124
Vigor2960 Series User's Guide
