Local IP / Subnet
Mask
Remote IP / Subnet
Mask
Netbios Naming
Packet
If you choose IPsec as the Type in Step 1, you will get the following page:
Available parameters are listed as follows:
Item
Profile
Enable
WAN Profile
Local IP/Subnet
Mask
Local Next Hop
Remote Host
Remote IP / Subnet
displayed here.
Type the IP address and subnet mask of local host.
Type the LAN IP address and LAN subnet mask for the
remote host.
Enable – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Disable –When there is conflict occurred between the hosts
on both sides of VPN Tunnel in connecting, such function
can block data transmission of Netbios Naming Packet inside
the tunnel.
Description
Display the name of the VPN profile.
Check this box to enable such profile.
Choose a WAN profile to be used by such profile.
Type the IP address and subnet mask of local host.
Specify the gateway for WAN interface. Usually, use the
default setting (leave it in blank).
Type the WAN IP address for the remote host.
Type the LAN IP address and LAN subnet mask for the
