Draytek Vigor2960 Series User Manual page 129

Delete
Refresh
Profile
Mode
Interface
Primary Profile
Backup Profile
There are two modes, Load Balance and Failover, for you to choose as the Pool
configuration. If you choose Load Balance, the tab of Load Balance will be shown which
allows you to configure for different WAN interfaces. If you choose Failover, the tab of
Failover will be displayed which allows you to specify the primary profile and backup
profile for such Pool setting.
Vigor2960 Series User's Guide
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
pool.
Remove the selected pool profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Renew current web page.
Display the name of the rule.
Display the protocol of such rule.
Display the name of the WAN profiles for Load Balance
rule.
Display the primary profile configured in Failover page for
such profile.
Display the backup profile configured in Failover page for
such profile.
121
