Draytek Vigor2960 Series User Manual page 97

4 4 . . 1 1 . . 3 3 . . 3 3
This page allows you to modify the status (enable / disable), speed(Auto,10M,100M,1000M)
and duplex (Half/Full) for the WAN ports respectively.
Each item will be explained as follows:
Item
Edit
Vigor2960 Series User's Guide
I I n n t t e e r r f f a a c c e e C C o o n n f f i i g g u u r
Description
Choose the interface listed below and click the Edit button
to modify the settings. A pop up window will appear for you
to change the settings.
Interface – Display the name of WAN interface.
Enable – Check it to enable such interface.
Speed – Use the drop down list to specify the transmission
rate (Auto, 10M, 100M or 1000M) for such interface.
Apply – Click it to save and exit the dialog.
r a a t t i i o o n n
89
