Draytek Vigor2960 Series User Manual page 202

H o w t o c r e a t e a n
H o w t o c r e a t e a n
1. Open Firewall>>MAC Block.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Enable
MAC Address
Apply
Cancel
4. Enter all of the settings and click Apply.
5. A new MAC Block profile has been created.
e w M A C B l o c k p r o
e w M A C B l o c k p r o
Description
Type the name which can briefly describe the reason of the
MAC block of such profile.
Check the box to enable this profile.
Type the MAC address which will be blocked by the system
for such profile.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
194
f i l e
f i l e
Vigor2960 Series User's Guide
