4 . 9 . 5 I P s e c G e
4 . 9 . 5 I P s e c G e
The IPsec services can provide access control, connectionless integrity, data origin
authentication, rejection of replayed packets that is a form of partial sequence integrity, and
confidentiality by encryption. These objectives are met through the use of two traffic
security protocols, the Authentication Header (AH) and the Encapsulating Security Payload
(ESP), and through the use of cryptographic key management procedures and protocols.
Available parameters are listed as follows:
Item
Preshared Key
WAN Profile
DHCP LAN Profile
IKE Port
NAT-T Port
IPsec MSS
GRE over IPsec MSS
Apply
Cancel
Enter all of the settings and click Apply.
Vigor2960 Series User's Guide
n e r a l S e t u p
n e r a l S e t u p
Description
Specify a key for IKE authentication
Confirm Pre-Shared Key- Retype the characters to confirm
the pre-shared key.
Choose a WAN interface profile to be used.
To clear the selected one, click
profile selections.
Choose one of the LAN profiles for VPN.
Type the UDP port number for Internet Key Exchange (IKE)
traffic to the VPN server.
Type the UDP port number for IPsec network address
translator traversal (NAT-T) traffic.
Type the port number for IPsec MSS.
Type the port number for GRE over IPsec MSS.
Click it to save the configuration.
Click it to discard the settings configured in this page.
307
to remove current
