NETGEAR ReadyDATA 5200 Software Manual page 28

Note: You can also use a shortcut to display the properties of a volume.
Click the screen Expand button (
display the properties (see the red oval in the previous figure). Click
the same button (which now shows a reversed arrow
hide the properties (see the red oval in the previous figure).
The following table explains the properties:
Item Description
Summary
RAID The configured RAID level.
Data The storage space that is consumed by data in MB, GB, or TB.
Snapshots The number of snapshots that have been taken.
Reserved The storage space that is reserved in MB, GB, or TB.
Free The storage space that is available in MB, GB, or TB and in a percentage.
Health The health of the volume. The options are:
• Online. The volume is healthy.
• Degraded. The volume is degraded.
ReadyDATA OS 1.2
) on the top right of the screen to
Manage Disks and Volumes
28
) again to
