150 Program features

User load curve

The user can specify a load curve (motor torque as a function of frequency) for
supervision. The curve is defined by five points. Supervision can be set for the torque
dropping below the underload curve, exceeding the overload curve, or both.
A fault is generated if the torque has been out of the allowed area for longer than the
user-defined time limit. An alarm is generated if the torque has been out of the
allowed area for longer than the half of the user-defined time limit.
Motor torque (%)
Torque
high 1
Allowed operating area
Torque
low 1
Freq. 1


Settings

Parameter
Group 37 USER LOAD CURVE


Diagnostics

Actual signal
0105
Alarm
USER LOAD CURVE
Fault
USER LOAD CURVE
PAR USER LOAD C
www.aotewell.com
Overload area
Torque
Torque
high 2
high 3
Torque
low 3
Torque
low 2
Underload area
Freq. 2 Freq. 3 Freq. 4
Additional information
User load curve settings
Additional information
Motor torque
Out of allowed area for longer than half of the defined
time limit
Out of allowed area for longer than the defined time
limit
Incorrect user load curve parameter setting
(3704 >
3716 or
3705 >
3715 or
sales@aotewell.com
Torque
high 4
Torque
low 4
3707 or 3707 > 3710
3706 or 3708 > 3709
3717 > 3718)
Industry Automation
Torque
high 5
Torque
low 5
Output
frequency (Hz)
Freq. 5
or 3710 > 3713 or 3713
or 3711 > 3712 or 3714
