xConfiguration Video Input Source [1..2] PresentationSelection
Define how the video system will behave when a presentation source is connected to the video
input. In general, any input source can be used as a presentation source; normally, the main camera
(self-view) will not be used as a presentation source.
If the video system is in standby mode, it will wake up when you connect a presentation source.
Note that sharing the presentation with the far end always requires additional action (tap Start
Presenting on the Touch controller, or press the Presentation key on the remote control).
Requires user role: ADMIN
Value space: <Manual/Automatic/OnConnect/Hidden>
Manual: In manual mode (default value), the contents of the input source will not be presented
on the screen until you select it. Use either the remote control or the Touch controller to choose
which input source to present.
Automatic: In automatic mode, the content on the input source will be presented on screen
automatically. If more than one source is set to Automatic, the last connected source will be used.
If any content was active (presented) when the call was disconnected, the content will still be
displayed locally.
OnConnect: When in on-connect mode, the content on the input source will be presented on
screen when a cable is connected. Otherwise, the behavior is like when in manual mode.
Hidden: In hidden mode, the contents of the input source do not appear in the graphical user
interface.
Example: xConfiguration Video Input Source 1 PresentationSelection: Manual
xConfiguration Video Input Source [1..2] Visibility
Define the visibility of the video input source in the menus on the user interface.
Requires user role: ADMIN
Value space: <Never/Always/IfSignal>
Never: Set to Never when the input source is not expected to be used as a presentation source.
Always: When set to Always, the menu selection for the video input source will always be visible
on the graphical user interface.
IfSignal: When set to IfSignal, the menu selection for the video input source will only be visible
when a presentation source is connected to the video input.
Example: xConfiguration Video Input Source 1 Visibility: IfSignal
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration xConfiguration
xConfiguration Video Input Source [1..2] CameraControl Mode
xConfiguration Video Input Source [1..2] CameraControl CameraId
72
xCommand
Select whether or not to enable camera control for the selected video input source when the video
input is active.
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable camera control.
On: Enable camera control.
Example: xConfiguration Video Input Source 1 CameraControl Mode: On
Indicates the ID of the camera. This value is fixed in this product.
Value space: <1>
Range: Indicates the ID of the camera.
