Parameter
TX Tcns
Desig Bridge ID
operEdge
Section 5.2.9
Managing Multiple Spanning Tree Instances
The following section describes how to configure and manage Multiple Spanning Tree Instances.
CONTENTS
•
Section 5.2.9.1, "Viewing Statistics for Global MSTIs"
•
Section 5.2.9.2, "Viewing Statistics for Port MSTIs"
•
Section 5.2.9.3, "Configuring the MST Region Identifier"
•
Section 5.2.9.4, "Configuring a Global MSTI"
•
Section 5.2.9.5, "Configuring an MSTI for an Ethernet Port"
Section 5.2.9.1
Viewing Statistics for Global MSTIs
To view statistics for global MSTIs, navigate to Spanning Tree » View Bridge MSTI Statistics . The Bridge MSTI
Statistics form appears.
Managing Multiple Spanning Tree Instances
Description
The count of STP topology change notification messages received
on this port. Excessively high or rapidly increasing counts signal
network problems.
Synopsis: 0 to 4294967295
The count of STP topology change notification messages transmitted
on this port.
Synopsis: $$ / ##-##-##-##-##-## where $$ is 0 to 65535, ## is 0
to FF
Provided on the root ports of designated bridges, the Bridge
Identifier of the bridge this port is connected to.
Synopsis: True or False
The port is operating as an edge port or not.
