4. Troubleshooting
4.6.17. Mx–xxxx (Tray not install_Paper empty_Outbin full)
Error Code Error Message
M1-3122 Tray 1 cassette is pulled out. Insert it properly
M1-3222 Tray 2 cassette is pulled out. Insert it properly
M1-4111 Tray Failure: #M1-4111. Pull tray 1 out and insert it. Call for service if the
problem persists
M1-4211 Tray Failure: #M1-4211. Pull tray 2 out and insert it. Call for service if the
problem persists
M1-5111 Paper is low in tray 1. Load paper
M1-5112 Paper is empty in tray 1. Load paper
M1-5113 Paper is empty in tray 1. Load paper
M1-5120 Paper is empty in all tray. Load paper
M1-5211 Paper is low in tray 2. Load paper
M1-5212 Paper is empty in tray 2. Load paper
M1-5612 Paper is empty in MP tray. Load paper
M3-2230 Paper in output bin is full. Remove printed paper
M3-2430 Paper in output bin is full. Remove printed paper
4-133 Copyright© 1995-2017 SAMSUNG. All rights reserved.
Troubleshooting Page
P.4–134
P.4–135
P.4–136
P.4–137
P.4–138
P.4–138
P.4–138
P.4–138
P.4–139
P.4–139
P.4–140
P.4–141
P.4–141
