xConfiguration UserInterface OSD Output

Define on which monitor the on-screen information and indicators (OSD) should be displayed.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration UserInterface OSD Output:
where
Output
: Auto/1/2
Auto: The system detects when a monitor is connected to a video output, and sends
the on-screen information and indicators to the first monitor you connect. If you have
a multi-monitor setup, and all monitors are connected before switching on the system,
the on-screen information and indicators are sent to the video output with the lowest
Typical resolutions used for different optimal definition profiles, call rates and frame rates
number, starting with Output Connector 1 (HDMI 1).
Optimal
Frame
Range 1-2: The system sends the on-screen information and indicators to the speci-
Definition
rate
fied output. Choose n to send the on-screen information and indicators to the system's
Profile 256 kbps 768 kbps
Output Connector n.
Normal 512 × 288 1024 × 576
Medium 640 × 360 1280 × 720
30 fps
High 768 × 448 1280 × 720
Normal 256 × 144 512 × 288
60 fps Medium 256 × 144 768 × 448
High 512 × 288 1024 × 576
SX20 Codec API Reference Guide CE8.1, APRIL 2016.
D15316.03
About the API xConfiguration xConfiguration
Output
Call rate
1152 kbps 1472 kbps 2560 kbps 4 Mbps
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080
1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080 1920 × 1080
768 × 448 1024 × 576 1280 × 720 1280 × 720 1920 × 1080
1024 × 576 1024 × 576 1280 × 720 1920 × 1080 1920 × 1080
1280 × 720 1280 × 720 1920 × 1080 1920 × 1080 1920 × 1080
xCommand

Video configuration

xConfiguration Video DefaultMainSource

Define which video input source shall be used as the main video source.
Requires user role: ADMIN, USER
Default value: 1
USAGE:
xConfiguration Video DefaultMainSource:
where
DefaultMainSource
: 1/2
Set the source to be used as the main video source.
xConfiguration Video Input Connector [1..2] CameraControl Mode
6 Mbps
Define whether the camera that is connected to this video input connector can be controlled or
not.
Note that camera control is not available for Connector 2 (DVI-I)
Requires user role: ADMIN
Default value: Connector 1: On Connector 2: Off
USAGE:
xConfiguration Video Input Connector
where
n
: Unique ID that identifies the video input connector. Range: 1..2
Mode
: Connector 1: Off/On Connector 2: Off
Off: Disable camera control.
On: Enable camera control.
81
API Reference Guide
xStatus Appendices
DefaultMainSource
CameraControl Mode:
n Mode
