BCD data represents decimal numbers in binary form. CPU32 BCD instructions use a
format in which a byte contains two digits — the four LSB contain the low digit, and the
four MSB contain the high digit. The ABCD, SBCD, and NBCD instructions operate on
two BCD digits packed into a single byte.
2.3.1.2 Address Registers
Each address register and stack pointer holds a 32-bit address. Address registers can-
not be used for byte-sized operands. When an address register is used as a source
operand, either the low-order word or the entire long-word operand is used, depending
upon the operation size. When an address register is used as a destination operand,
the entire register is affected, regardless of operation size. If the source operand is a
word, it is first sign extended to 32 bits, and then used in the operation. Address reg-
isters can be used to support address computation. The instruction set includes in-
structions that add to, subtract from, compare, and move the contents of address
registers. Figure 2-5 shows the organization of addresses in address registers.
31
SIGN EXTENDED
31
Figure 2-5 Address Organization in Address Registers
2.3.1.3 Control Registers
The control registers contain control information for supervisor functions. The registers
vary in size. With the exception of the user portion of the SR (CCR), they are accessed
only by instructions at the supervisor privilege level.
The SR shown in Figure 2-3 is 16 bits wide. Only 11 bits of the SR are defined, and
all undefined values are reserved by Motorola for future definition. The undefined bits
are read as zeros and should be written as zeros for future compatibility. The lower
byte of the SR is the CCR. Operations to the CCR can be performed at the supervisor
or user privilege level. All operations to the SR and CCR are word-size operations. For
all CCR operations, the upper byte is read as all zeros and is ignored when written,
regardless of privilege level.
The alternate function code registers (SFC and DFC) are 32-bit registers with only bits
[2:0] implemented. These bits contain address space values (FC2 to FC0) for the read
or write operand of the MOVES instruction. The MOVEC instruction is used to transfer
values to and from the alternate function code registers. These are long-word transfers
— the upper 29 bits are read as zeros and are ignored when written.
CPU32
REFERENCE MANUAL
16 15
FULL 32-BIT ADDRESS OPERAND
ARCHITECTURE SUMMARY
16-BIT ADDRESS OPERAND
0
0
MOTOROLA
2-5
